Glow-worm
Glow-worm Microswitch + 2 Cable S801199
Microswitch with two cables for Glow-worm Compact and Saunier Duval SD 30E gas boilers, part number S801199.
At a glance
- Also known as 1336601
£40.30
£33.58 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Glow-worm S801199 is a microswitch supplied with two cables, used in Glow-worm Compact gas boilers. It sits in the boiler's switching circuit, where the contacts signal the control board when an actuator or mechanism reaches its set position. It is a serviceable electrical spare for the Compact range and the Saunier Duval SD 30E.
Signs this part needs replacing
- Boiler fails to fire or ignite when there is a call for heat
- Intermittent running — the boiler cuts in and out without a clear fault code
- Fan, pump or diverter sequence does not start as expected
- Switch contacts show burning, pitting or a loose lever
- Cable insulation or terminal connections are damaged or brittle
Before you order
- Confirm the boiler model and GC number against the appliance data badge
- Check the existing microswitch for the same number of cables and terminal arrangement
- Isolate the electrical supply before removing or fitting the switch
- Inspect the wiring harness and connectors for damage before fitting
Compliance
| GC number | E27-185 |
|---|---|
| Barcode / EAN | 4024074501399 |
| Alternative numbers | 1336601 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| GLOWWORM COMPACT 100 SEALED SYSTEM | 41-047-26 | 41-047-26 | — | — |
| GLOWWORM COMPACT 100E | 47-047-08A | 47-047-08A | — | — |
| GLOWWORM COMPACT 60 SEALED SYSTEM | 41-047-27 | 41-047-27 | — | — |
| GLOWWORM COMPACT 75E | 47-047-06A | 47-047-06A | — | — |
| GLOWWORM COMPACT 80E | 47-047-07A | 47-047-07A | — | — |
| GLOWWORM GLOWWORM COMPACT 100 SEALED SYSTEM | — | — | — | |
| GLOWWORM GLOWWORM COMPACT 100E | — | — | — | |
| GLOWWORM GLOWWORM COMPACT 75E | — | — | — | |
| GLOWWORM GLOWWORM COMPACT 80E | — | — | — | |
| SAUNIER DUVAL SAUNIER DUVAL SD 30E | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
No technical questions yet for this part.
