Worcester Bosch
Worcester Bosch Printed Circuit Board Greenstar Heatslave 87186852610
Worcester Bosch 87186852610 printed circuit board for Greenstar Heatslave boilers, controlling the appliance's operating sequence.
At a glance
- Part type: Printed circuit board (PCB)
- Appliance family: Greenstar Heatslave
- Also known as 1022729
£300.64
£250.53 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Worcester Bosch 87186852610 is a printed circuit board (PCB) supplied for the Greenstar Heatslave family of boilers. It is the main control board, handling the appliance's operating sequence, burner demand and the safety interlocks that sit behind normal running. The board is a direct replacement item for the original fitted unit and carries the Worcester brand.
Signs this part needs replacing
- The boiler fails to fire, or locks out repeatedly after resetting.
- No heating or hot water even though the programmer and thermostat are calling for demand.
- A blank, dead or unresponsive display, or no indicator LEDs on the board.
- The burner lights briefly and then shuts down before the appliance reaches temperature.
- The board fuse blows again shortly after being replaced.
Before you order
- Check the model and serial number on the appliance data badge against the compatibility list before ordering.
- Compare the part number printed on the existing board with 87186852610; older boards may carry the number ZAGAS278.
- Cross-reference the alternative codes 1022729 and WB87186852610 if you are working from an older parts listing.
- Replacement involves opening the boiler casing and working on the appliance electrics, so the work should be carried out by a competent person.
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Appliance family | Greenstar Heatslave |
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 87186852610 |
|---|---|
| Barcode / EAN | 4047416163413 |
| Commodity code | 8537 10 91 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | WB87186852610, ZAGAS278, 1022729 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| WORCESTER GREENSTAR HEATSLAVE EXTERNAL 12/18 | — | — | — | |
| WORCESTER GREENSTAR HEATSLAVE EXTERNAL 18/25 | — | — | — | |
| WORCESTER GREENSTAR HEATSLAVE EXTERNAL 25/32 | — | — | — | |
| WORCESTER GREENSTAR HEATSLAVE HE 12/18 INTERNAL | — | — | — | |
| WORCESTER GREENSTAR HEATSLAVE HE 18/25 INTERNAL | — | — | — | |
| WORCESTER GREENSTAR HEATSLAVE HE 25/32 INTERNAL | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HEATSLAVE 12/18 EXTERNAL | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HEATSLAVE 12/18 OSO | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HEATSLAVE 18/25 EXTERNAL | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HEATSLAVE 18/25 OSO | — | — | — |
Showing 10 of 36 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
WORCESTER appliance manual — GREENSTAR HEATSLAVE EXTERNAL 12/18, GREENSTAR HEATSLAVE EXTERNAL 18/25, GREENSTAR HEATSLAVE EXTERNAL 25/32
manualmanualWORCESTER appliance manual — GREENSTAR HEATSLAVE HE 12/18 INTERNAL, GREENSTAR HEATSLAVE HE 18/25 INTERNAL, GREENSTAR HEATSLAVE HE 25/32 INTERNAL
manualNo technical questions yet for this part.
