Worcester Bosch
Worcester Bosch Fan Assembly 24i FSN 8716119948
At a glance
- Part type: Fan assembly
- Appliance family: 24i RSF combi
- Also known as 1016602
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£307.91
£256.59 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Worcester Bosch 8716119948 is a fan assembly used on the 24i RSF range of gas combi boilers. It draws combustion air into the burner and drives the products of combustion out through the flue, and it supplies the air pressure signal the boiler control board uses to prove the fan is running before it allows ignition. Because the fan sits at the heart of the combustion sequence, a worn or failing unit will usually stop the boiler firing altogether.
Signs this part needs replacing
- Whining, grinding or rumbling noise from the fan housing when the boiler starts
- Boiler attempts to fire but locks out, with no sustained flame
- Fan proving or air pressure fault indicated by the boiler controls
- Fan runs intermittently, or the boiler locks out at random during a demand
- Repeated lockouts that clear on reset and return shortly afterwards
Before you order
- Check the model and GC number on the boiler data badge against the compatibility list below before ordering.
- Compare the number on the existing fan with 8716119948; the earlier numbers 8-716-120-993-0, 87161209930 and SSA011994 identify the same assembly.
- Inspect the fan mounting gasket and flue connections for damage while the boiler is open, and renew any seal that has hardened or split.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Fan assembly |
|---|---|
| Appliance family | 24i RSF combi |
Compliance
| Manufacturer part number (MPN) | 8716119948 |
|---|---|
| GC number | 47-311-37 |
| Barcode / EAN | 8716119948 |
| Commodity code | 8414 59 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | WB8716119948, 8-716-120-993-0, SSA011994, 1016602 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| WORCESTER 24i RSF COMBI NG (NOV 2004) | 47-311-37 | 47-311-37 | — | — |
| WORCESTER 24i RSF COMBI NG (SEP 2001) | 47-311-37 | 47-311-37 | — | — |
| WORCESTER WORCESTER 24I RSF NATURAL GAS | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
No technical questions yet for this part.
Not sure which part?
Search by part number, product name or brand — our technical team confirms fitment before anything is dispatched.
