Worcester Bosch
Worcester Bosch Fan Wiring Harness 8716118195
Worcester Bosch fan wiring harness, part 8716118195, for Greenstar Highflow 440CDi and 550CDi ErP boilers in LPG and NG variants.
At a glance
- Part type: Cables, leads and wiring harnesses
- Also known as 2244999
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£28.07
£23.39 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Worcester Bosch 8716118195 is a fan wiring harness — the cable assembly that carries power and control signals between the boiler's fan and the main control board. It is a Worcester Bosch spare supplied for the Greenstar Highflow CDi ErP range of condensing boilers. The harness sits inside the appliance casing, so it is exposed to heat and vibration over its service life and can be damaged or work loose.
Signs this part needs replacing
- The fan does not run when the boiler is called for heat, with no obvious fault at the fan itself
- Intermittent fan operation or the boiler cutting out shortly after ignition
- Fault codes relating to the fan or flue system appearing on the boiler display
- Visible damage to the harness: chafed, brittle or heat-hardened insulation, or exposed conductors
- A loose, corroded or partially seated connector at the fan or PCB end
Before you order
- Check the GC number on your appliance data badge against the list above before ordering, as the harness is model-specific
- Confirm the alternative number 2244999 matches the part you are replacing
- Inspect the fan and its mounting gasket while the casing is open, as these are commonly disturbed during replacement
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Cables, Leads & Wiring Harnesses |
|---|
Compliance
| Manufacturer part number (MPN) | 8716118195 |
|---|---|
| Barcode / EAN | 8716118195 |
| Commodity code | 8544 42 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 2244999 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| WORCESTER GREENSTAR HIGHFLOW 440CDi ErP LPG (7731600099) | 47-406-90 | 47-406-90 | — | — |
| WORCESTER GREENSTAR HIGHFLOW 440CDi ErP NG (7731600098) | 47-406-89 | 47-406-89 | — | — |
| WORCESTER GREENSTAR HIGHFLOW 550CDi ErP LPG (7731600101) | 47-406-92 | 47-406-92 | — | — |
| WORCESTER GREENSTAR HIGHFLOW 550CDi ErP NG (7731600100) | 47-406-91 | 47-406-91 | — | — |
| WORCESTER WORCESTER GREENSTAR HIGHFLOW 440CDi ErP LPG | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HIGHFLOW 440CDi ErP NG | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HIGHFLOW 550CDi ErP LPG | — | — | — | |
| WORCESTER WORCESTER GREENSTAR HIGHFLOW 550CDi ErP NG | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
No technical questions yet for this part.
