Worcester Bosch Diverter Valve Assembly Mixer Module 87161068450
At a glance
- Part type: Diverter valve assembly / mixer module
- Appliance family: Greenstar and Greenstar ErP
- Also known as 1015099, N9101
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Showing prices
£140.00
£116.67 ex. VAT · VAT at 20%
In stock
Cut-off passed — dispatches next working day
Not certain it's the right part? The technical team verifies fitment before dispatch — no charge, and it stops a second trip.Call the technical teamSend a technical question
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Worcester Bosch mixer module diverter valve assembly is a hydraulic component used in Greenstar and Greenstar ErP boilers. It sits within the boiler's water circuit and directs the flow of heated water either into the central heating system or into the domestic hot water circuit. On a combi appliance this switching action is what allows the boiler to supply both heating and hot water on demand without a separate storage cylinder.
Signs this part needs replacing
- Domestic hot water runs cold or only lukewarm while the heating circuit works normally
- Heating circuit warms when only hot water is called for, or hot water is produced when only heating is demanded
- Radiators stay cold while the boiler fires for a hot water demand
- Diverter valve sticking, with the boiler cycling between heating and hot water modes
- Reduced or inconsistent hot water temperature at the tap
Before you order
- Check the GC number on the appliance data badge against the numbers listed for this part before ordering.
- Confirm the model and serial number of the boiler, as this assembly is used across a large number of Greenstar and Greenstar ErP variants.
- Check whether a gasket or seal kit is needed for the joint being disturbed during the swap.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Diverter & Motorised Valves |
|---|---|
| Appliance family | Greenstar, Greenstar ErP |
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 87161068450 |
|---|---|
| GC number | H02-533 |
| Barcode / EAN | 4010009876175 |
| Commodity code | 8481 80 90 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | WB87161068450, 1015099, N9101 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| WORCESTER BRITISH GAS 430/I | 41-311-80 | 41-311-80 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 430/I SYSTEM LPG | 41-311-81 | 41-311-81 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 532/I COMBI LPG | 47-406-03 | 47-406-03 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 532/I COMBI NG | 47-406-02 | 47-406-02 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 537/I COMBI LPG | 47-406-05 | 47-406-05 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 537/I COMBI NG | 47-406-04 | 47-406-04 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 542/I COMBI LPG | 47-406-07 | 47-406-07 | — | — |
| WORCESTER BRITISH GAS GREENSTAR 542/I COMBI NG | 47-406-06 | 47-406-06 | — | — |
| WORCESTER GREENSTAR 12i SYSTEM LPG | 41-311-69 | 41-311-69 | — | — |
| WORCESTER GREENSTAR 12i SYSTEM NG | 41-311-67 | 41-311-67 | — | — |
Showing 10 of 289 compatible appliances.
Fitment listings are a guide, not a guarantee. Plant-room assemblies get modified on site more often than not. Send us the GC number off the data badge and a photo of the existing valve and we will confirm before anything is dispatched.
