Worcester Bosch Pipe Elbow 87161067180
Worcester Bosch pipe elbow, part 87161067180, for routing water or gas through Greenstar internal pipework. Alternative number 1015043.
At a glance
- Part type: Elbow
- Also known as 1015043
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£11.50
£9.58 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Worcester Bosch pipe elbow, part number 87161067180, is a formed internal pipework fitting used inside Worcester Bosch gas boilers. It sits within the appliance's internal pipe runs and directs the flow of water or gas along the correct route, so the boiler's hydraulic and gas circuits behave as designed. It is a Worcester Bosch spare belonging to the Greenstar appliance family.
Signs this part needs replacing
- Visible corrosion, pitting or surface staining on the elbow body or at the joint faces
- Damp patches, weeping or a slow drip where the elbow meets the adjoining pipe
- A drop in system pressure that cannot be traced to any other part of the circuit
- Scale or debris build-up inside the bore, restricting flow through the pipe run
- Disturbed or damaged pipework following earlier work on the appliance
Before you order
- Check the GC number and appliance serial number against the compatibility list to confirm the elbow suits your model
- Note the alternative part number 1015043 when cross-referencing older documentation or stock records
- Inspect the joint seal on removal and replace it if it shows signs of hardening, cracking or flattening
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Elbows |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 87161067180 |
|---|---|
| GC number | H04-639 |
| Barcode / EAN | 4010009872207 |
| Commodity code | 7412 20 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1015043 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| WORCESTER GREENSTAR 12RI NG | 41-311-63 | 41-311-63 | — | — |
| WORCESTER GREENSTAR 12i SYSTEM LPG | 41-311-69 | 41-311-69 | — | — |
| WORCESTER GREENSTAR 12i SYSTEM NG | 41-311-67 | 41-311-67 | — | — |
| WORCESTER GREENSTAR 21Ri ErP+ LPG | 41-406-72 | 41-406-72 | — | — |
| WORCESTER GREENSTAR 21Ri ErP+ NG | 41-406-78 | 41-406-78 | — | — |
| WORCESTER GREENSTAR 24I JUNIOR MK5 LPG | 47-406-55 | 47-406-55 | — | — |
| WORCESTER GREENSTAR 24I JUNIOR MK5 NG | 47-406-54 | 47-406-54 | — | — |
| WORCESTER GREENSTAR 24I JUNIOR NG | 47-311-86 | 47-311-86 | — | — |
| WORCESTER GREENSTAR 24RI LPG | 41-311-66 | 41-311-66 | — | — |
| WORCESTER GREENSTAR 24RI NG | 41-311-65 | 41-311-65 | — | — |
Showing 10 of 29 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
WORCESTER appliance manual — GREENSTAR 12RI NG (GC 41-311-63), GREENSTAR 24RI LPG (GC 41-311-66), GREENSTAR 24RI NG (GC 41-311-65)
manualmanualWORCESTER appliance manual — GREENSTAR 12i SYSTEM LPG (GC 41-311-69), GREENSTAR 12i SYSTEM NG (GC 41-311-67), GREENSTAR 24i SYSTEM LPG (GC 41-311-70), GREENSTAR 24i SYSTEM NG (GC 41-311-68)
manualmanualWORCESTER appliance manual — GREENSTAR 21Ri ErP+ LPG (GC 41-406-72), GREENSTAR 21Ri ErP+ NG (GC 41-406-78), GREENSTAR 24Ri ErP+ LPG (GC 41-406-73), GREENSTAR 24Ri ErP+ NG (GC 41-406-79)
manualmanualWORCESTER appliance manual — GREENSTAR 24I JUNIOR MK5 LPG (GC 47-406-55), GREENSTAR 24I JUNIOR MK5 NG (GC 47-406-54), GREENSTAR 24I JUNIOR NG (GC 47-311-86), GREENSTAR 24i JUNIOR LPG (GC 47-311-90), GREENSTAR 28I JUNIOR MK5 LPG (GC 47-406-57), GREENSTAR 28I JUNIOR MK5 NG (GC 47-406-56), GREENSTAR 28i JUNIOR LPG (GC 47-311-91), GREENSTAR 28i JUNIOR NG (GC 47-311-87)
manualmanualWORCESTER appliance manual — GREENSTAR 24Ri ErP LPG (GC 41-406-48), GREENSTAR 24Ri ErP NG (GC 41-406-47)
manualmanualWORCESTER appliance manual — GREENSTAR 25SI COMBI LPG (GC 47-311-88), GREENSTAR 25SI COMBI NG (GC 47-311-84), GREENSTAR 30 SI COMBI LPG (GC 47-311-89), GREENSTAR 30 SI COMBI NG (GC 47-311-85)
manualNo technical questions yet for this part.
