Worcester Bosch Combustion Chamber Seal Plate 87107031820
Worcester Bosch combustion chamber seal plate, part 87107031820, for Greenstar combi and condensing models; supplied singly.
At a glance
- Part type: Gaskets, seals and O-rings
- Also known as 1012437
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Showing prices
£40.63
£33.86 ex. VAT · VAT at 20%
Available to order · 3 working days
Available to order · 3 working days
Not certain it's the right part? The technical team verifies fitment before dispatch — no charge, and it stops a second trip.Call the technical teamSend a technical question
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The combustion chamber seal plate is a Worcester Bosch sealing component that closes the combustion chamber opening on Greenstar gas boilers. It forms the gas-tight boundary between the combustion chamber and the surrounding casing, so the seal must be sound for correct combustion and safe flue operation. The plate is supplied as a single item and is listed under Worcester Bosch's gaskets, seals and O-rings range.
Signs this part needs replacing
- Visible distortion, cracking or hardening of the seal plate or its sealing face
- Soot staining, discolouration or heat marks around the combustion chamber cover
- Water or condensate traces weeping past the combustion chamber joint
- Combustion readings drifting outside the expected range on a flue gas analyser
- A smell of combustion products or evidence of leakage at the chamber joint during a service
Before you order
- Check the appliance GC number and model against the compatibility list before ordering, as the same part number covers a number of Greenstar variants.
- Confirm the number on the existing component or in the appliance documentation matches 87107031820 or the alternative number 1012437.
- Assess whether any associated gaskets, seals or fixings disturbed during removal also need replacing.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | SEAL-PLATE-COMBUSTION CHAMBER |
|---|
Compliance
| Manufacturer part number (MPN) | 87107031820 |
|---|---|
| GC number | E74-518 |
| Barcode / EAN | 4010009616498 |
| Commodity code | 8403 90 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1012437 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| WORCESTER BRITISH GAS GREENSTAR CC1-FSN-GB NG 29KW COMBI | 47-108-05 | 47-108-05 | — | — |
| WORCESTER BRITISH GAS GREENSTAR GREENSTAR HE PLUS-FSN- GB28KW | 47-311-56 | 47-311-56 | — | — |
| WORCESTER BRITISH GAS GREENSTAR GREENSTAR HE-FSN-GB NG 27KW | 47-311-55 | 47-311-55 | — | — |
| WORCESTER BRITISH GAS GREENSTAR ICC2-FSN-GB NAT 30KW COND COM | 41-108-09 | 41-108-09 | — | — |
| WORCESTER BRITISH GAS GREENSTAR ICC2-FSN-GB NAT 37KW COND COM | 41-108-10 | 41-108-10 | — | — |
| WORCESTER BRITISH GAS GREENSTAR RD428 | 41-108-07 | 41-108-07 | — | — |
| WORCESTER BRITISH GAS GREENSTAR RD537I | 47-108-11 | 47-108-11 | — | — |
| WORCESTER BRITISH GAS RD430I | 41-108-06 | 41-108-06 | — | — |
| WORCESTER BRITISH GAS RD532 | 47-108-13 | 47-108-13 | — | — |
| WORCESTER BRITISH GAS RD532I | 47-108-10 | 47-108-10 | — | — |
Showing 10 of 61 compatible appliances.
Fitment listings are a guide, not a guarantee. Plant-room assemblies get modified on site more often than not. Send us the GC number off the data badge and a photo of the existing valve and we will confirm before anything is dispatched.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
manual
WORCESTER appliance manual — BRITISH GAS GREENSTAR ICC2-FSN-GB NAT 30KW COND COM (GC 41-108-09), BRITISH GAS GREENSTAR ICC2-FSN-GB NAT 37KW COND COM (GC 41-108-10)
manualmanualWORCESTER appliance manual — CS1 RSF 28KW NG (GC 41-108-02)
manualmanualWORCESTER appliance manual — GREENSTAR 25 HE (GC 47-311-73), GREENSTAR 30 HE COMBI (GC 47-311-74)
manualmanualWORCESTER appliance manual — GREENSTAR 28 HE SYSTEM (GC 41-311-58)
manualmanualWORCESTER appliance manual — GREENSTAR 29 HE CONVENTIONAL (JAN 2003) (GC 41-311-59), GREENSTAR 29 HE CONVENTIONAL (JUN 2002) (GC 41-311-56)
manualmanualWORCESTER appliance manual — GREENSTAR 30 HE PLUS COMBI (GC 47-311-75), GREENSTAR 35 HE PLUS COMBI (GC 47-311-76), GREENSTAR HE PLUS-FSN-GB35KW (GC 47-311-57)
manualmanualWORCESTER appliance manual — GREENSTAR R25HE COMBI (GC 47-311-77), GREENSTAR R30HE COMBI (GC 47-311-78)
manualmanualWORCESTER appliance manual — GREENSTAR R28HE SYSTEM (GC 41-311-62)
manualmanualWORCESTER appliance manual — GREENSTAR R29HE CONVENTIONAL (GC 41-311-60), GREENSTAR R40HE CONVENTIONAL (GC 41-311-61)
manualmanualWORCESTER appliance manual — GREENSTAR R30HE PLUS COMBI (GC 47-311-79), GREENSTAR R35HE PLUS COMBI (GC 47-311-80), GREENSTAR R40HE PLUS COMBI (GC 47-311-81)
manualmanualWORCESTER appliance manual — ICS1 RSF 28KW NG (GC 41-108-04)
