Viessmann O-Ring Set 9.6 X 2.4 (5PCS) 7826216
Viessmann O-ring set, 9.6 x 2.4, 5 pieces, for the water pressure sensor on Vitodens gas boilers.
At a glance
- Also known as 2320212
£14.40
£12.00 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
This five-piece O-ring set (SKU 7826216) from Viessmann seals the water pressure sensor on Vitodens gas boilers. The sensor is fitted to the hydraulic circuit, and the O-rings maintain a watertight joint at that connection. The set is listed in the Gas Boiler Spares range.
Signs this part needs replacing
- Water visible around the water pressure sensor connection or on the surrounding pipework
- Slow loss of system pressure that needs regular topping up
- Boiler showing a low water pressure fault or lockout code
- Perished, flattened, cracked or hardened O-rings when the sensor is removed
- Dampness or staining on the boiler casing near the sensor
Before you order
- Measure the existing O-rings. The product name lists 9.6 x 2.4, while the catalogue description gives 10mm x 2mm, so confirm the size against the seal being replaced.
- Check the boiler model and serial number against the fitment list above.
- Confirm the boiler was manufactured on or after 20.06.2007, as the listing applies from that date.
- Check that the set contains five O-rings before fitting, and keep spares in case a seal is damaged during removal.
Compliance
| Alternative numbers | 2320212 |
|---|
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| VIESSMANN VITODENS 050-W B0KA 25KW SERIAL No. 7959979 | 47-819-55 | 47-819-55 | — | — |
| VIESSMANN VITODENS 050-W B0KA 30KW SERIAL No. 7959980 | — | — | — | |
| VIESSMANN VITODENS 050-W B0KA-M 25KW SERIAL No. 7721984 | 47-819-56 | 47-819-56 | — | — |
| VIESSMANN VITODENS 100-W B1HF 11KW SYSTEM SERIAL No. 7723177 | 41-819-51 | 41-819-51 | — | — |
| VIESSMANN VITODENS 100-W B1HF 19 KW SYSTEM SERIAL No. 7723178 | 41-819-48 | 41-819-48 | — | — |
| VIESSMANN VITODENS 100-W B1HF 25 KW SYSTEM SERIAL No. 7723179 | 41-819-49 | 41-819-49 | — | — |
| VIESSMANN VITODENS 100-W B1HF 32 KW SYSTEM SERIAL No. 7723180 | 41-819-50 | 41-819-50 | — | — |
| VIESSMANN VITODENS 100-W B1KA 26 KW COMBI ERP SERIAL No. 7543422 | 47-819-33 | 47-819-33 | — | — |
| VIESSMANN VITODENS 100-W B1KA 30 KW COMBI ERP SERIAL No. 7543424 | 47-819-34 | 47-819-34 | — | — |
| VIESSMANN VITODENS 100-W B1KA 35 KW COMBI ERP SERIAL No. 7543426 | 47-819-35 | 47-819-35 | — | — |
Showing 10 of 61 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
VIESSMANN appliance manual — VITODENS 222-F B2TB 19 SERIAL NO. 7542250, VITODENS 222-F B2TB 35 SERIAL NO. 7542251
manualmanualVIESSMANN appliance manual — VITODENS WB1A COMBI C24KW SERIAL No. 7248590, VITODENS WB1A COMBI C30KW SERIAL No. 7248589
manualmanualVIESSMANN appliance manual — VITODENS WB1C 100-W 26KW COMBI SERIAL No. 7499425 (GC 47-819-20), VITODENS WB1C 100-W 30 KW COMBI SERIAL No. 7499427 (GC 47-819-21), VITODENS WB1C 100-W 35 KW COMBI SERIAL No. 7499429 (GC 47-819-22)
manualNo technical questions yet for this part.
