Viessmann Interlocking Type Connector Kit 7825701
Interlocking type connector kit for Viessmann Vitodens gas boilers, suitable for models manufactured from 02.03.2006.
At a glance
- Also known as 2320590
- Installation must be carried out by a Gas Safe registered engineer.
£8.63
£7.19 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Viessmann Interlocking Type Connector Kit is a component for Viessmann Vitodens gas boilers. It is identified by part number 7825701 and is specified for appliances manufactured from 02.03.2006. The kit is used within the boiler assembly to provide an interlocking connection.
Signs this part needs replacing
- Visible cracks, corrosion or heat damage on the connector
- Loose or intermittent electrical contact causing boiler faults
- Boiler lockout or ignition failure linked to the connector
- Signs of gas leakage around the connector (detected by smell or leak detector)
- Physical deterioration from age or thermal cycling
Before you order
- Confirm your boiler model and serial number match the list in the Fits section.
- Check that your appliance was manufactured from 02.03.2006 onwards.
- Verify the part number 7825701 on your existing component or in the manufacturer's parts list.
- Installation must be carried out by a Gas Safe registered engineer.
Compliance
| Alternative numbers | 2320590 |
|---|
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| VIESSMANN VITODENS 333-F WS3A SERIAL No. 7190614 | 47-819-07 | 47-819-07 | — | — |
| VIESSMANN VITODENS 343-F WS4A SERIAL No. 7288384 | 47-819-08 | 47-819-08 | — | — |
| VIESSMANN VITODENS WB3A COMBI 26KW | — | — | — | |
| VIESSMANN VITODENS WB3A COMBI 26KW SERIAL No. 7176538 | — | — | — | |
| VIESSMANN VITODENS WB3A SYSTEM 26KW | — | — | — | |
| VIESSMANN VITODENS WB3A SYSTEM 26KW SERIAL No. 7176537 | — | — | — | |
| VIESSMANN VITODENS WB3A SYSTEM 35KW | — | — | — | |
| VIESSMANN VITODENS WB3A SYSTEM 35KW SERIAL No. 7176539 | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
No documents held for this part. The technical team will source them from the manufacturer — usually the same working day.
No technical questions yet for this part.
