Viessmann Boiler Sensor 7819967
Viessmann sensor 3 (7819967) thermistor for Vitodens WB1/WB2 boilers and DHW, used from 15.01.2004.
At a glance
- Also known as TEMPERATURE-SENSOR, 2320068, N8934
£103.52
£86.27 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Viessmann 7819967 is sensor 3, a thermistor used for boiler and domestic hot water temperature sensing on Vitodens appliances. It is specified for WB1 and WB2 generation boilers built from 15 January 2004. The sensor reports temperature back to the boiler control, which uses the signal for modulation and safety monitoring.
Signs this part needs replacing
- Boiler locks out or fails to fire with a sensor-related fault code
- Domestic hot water temperature fluctuates or runs hot and cold
- Flow or return temperature readings on the display are implausible or erratic
- Resistance measured at the sensor falls outside the expected range for the ambient temperature
- Boiler short-cycles or modulates poorly because the control is receiving incorrect temperature data
Before you order
- Confirm the appliance model and serial number against the fitment list above
- Check the GC number where shown, as several Vitodens variants share similar model names
- Identify the sensor position on the appliance to confirm sensor 3 is the one being replaced
- Compare the connector and mounting of the removed sensor with the part before fitting
Compliance
| Alternative numbers | TEMPERATURE-SENSOR, 2320068, N8934 |
|---|
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| VIESSMANN VITODENS 050-W BPJC 29 KW COMBI SERIAL No. 7537906 | 47-819-31 | 47-819-31 | — | — |
| VIESSMANN VITODENS 050-W BPJC 35 KW COMBI SERIAL No. 7537947 | 47-819-32 | 47-819-32 | — | — |
| VIESSMANN VITODENS 050-W BPJD 29KW COMBI SERIAL No. 7202938 | 47-819-38 | 47-819-38 | — | — |
| VIESSMANN VITODENS 050-W BPJD 35 KW COMBI SERIAL No. 7202939 | 47-819-39 | 47-819-39 | — | — |
| VIESSMANN VITODENS 100 SYSTEM 24KW | — | — | — | |
| VIESSMANN VITODENS 100 SYSTEM BOILER 24KW SERIAL No. 7179918 | — | — | — | |
| VIESSMANN VITODENS 100-W B1HA 19 KW SYSTEM ERP SERIAL No. 7543420 | 41-819-36 | 41-819-36 | — | — |
| VIESSMANN VITODENS 100-W B1HA 26 KW SYSTEM ERP SERIAL No. 7543421 | 41-819-37 | 41-819-37 | — | — |
| VIESSMANN VITODENS 100-W B1HA 26 SERIAL No. 7560853 | — | — | — | |
| VIESSMANN VITODENS 100-W B1HA 30 KW SYSTEM ERP SERIAL No. 7543423 | 41-819-38 | 41-819-38 | — | — |
Showing 10 of 154 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
VIESSMANN appliance manual — VITODENS 100 SYSTEM BOILER 24KW SERIAL No. 7179918, VITODENS WB1A COMBI 24KW SERIAL No. 7179917, VITODENS WB1A COMBI 30KW SERIAL No. 7179916 (GC 47-819-05), VITODENS WB1A COMBI C24KW SERIAL No. 7246794, VITODENS WB1A COMBI C24KW SERIAL No. 7247428, VITODENS WB1A COMBI C24KW SERIAL No. 7248590, VITODENS WB1A COMBI C30KW SERIAL No. 7248589
manualmanualVIESSMANN appliance manual — VITODENS WB1C 100-W 19 KW SYSTEM SERIAL No. 7499423 (GC 41-819-26), VITODENS WB1C 100-W 26 KW SYSTEM SERIAL No. 7499424 (GC 41-819-27), VITODENS WB1C 100-W 26KW COMBI SERIAL No. 7499425 (GC 47-819-20), VITODENS WB1C 100-W 30 KW COMBI SERIAL No. 7499427 (GC 47-819-21), VITODENS WB1C 100-W 30 KW SYSTEM SERIAL No. 7499426 (GC 41-819-28), VITODENS WB1C 100-W 30KW GB COMBI SERIAL No. 7441745 (GC 47-819-21), VITODENS WB1C 100-W 35 KW COMBI SERIAL No. 7499429 (GC 47-819-22), VITODENS WB1C VITODENS 100-W 35 KW SYSTEM SERIAL No. 7499428 (GC 41-819-29)
manualNo technical questions yet for this part.
Not sure which part?
Search by part number, product name or brand — our technical team confirms fitment before anything is dispatched.
