Baxi Burner Assembly 30/39kW 720541601

The Baxi 720541601 is a burner assembly rated for 30/39kW operation, manufactured by Baxi for the Avanta range of gas combi boilers. It sits at the heart of the combustion process, presenting the gas and air mixture at the burner head so that it ignites evenly across the surface and produces a stable flame into the heat exchanger. The assembly is common to both Baxi and Broag Remeha badged versions of the same 39C combi platform.

• A yellow, orange or lazy flame where a crisp blue flame is expected
• Soot deposits or blackening around the burner head, combustion chamber or heat exchanger
• Repeated ignition lockout, delayed ignition or failure to light
• Flame lift, flame roll-out or unusual roaring and popping noises at start-up
• Elevated carbon monoxide readings during flue gas analysis
• Visible distortion, corrosion or cracking of the burner surface on inspection

• Check the GC number on the appliance data badge against the compatibility list above before ordering.
• The previous number S62740 identifies the same burner assembly on older stock and service records.
• Inspect the burner gasket and seals while the burner is removed, and renew them if they show signs of hardening or damage.
• This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
