Ariston
Ariston Burner 24kW ARISTON60000288-01
At a glance
- Part type: Burner
- Appliance family: Clas HE EVO, E-Combi EVO 24, System
- Also known as ARISTON60000288-01
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Showing prices
£156.00
£130.00 ex. VAT · VAT at 20%
In stock
Order within 5m for same-day dispatch
Not certain it's the right part? The technical team verifies fitment before dispatch — no charge, and it stops a second trip.Call the technical teamSend a technical question
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ariston 60000288-01 is a 24 kW gas burner assembly used in Ariston Clas HE EVO, E-Combi EVO 24 and System boilers. It sits at the heart of the combustion process, mixing gas and air and presenting the flame to the heat exchanger so that heat transfers into the primary water circuit. This version carries the -01 suffix and replaces the earlier 60000288 burner.
Signs this part needs replacing
- The boiler locks out on ignition or fails to light consistently
- A lazy, yellow or lifting flame instead of a steady blue flame
- Sooting or blackening around the burner surface or combustion chamber
- Flame failure or flame supervision faults appearing during operation
- Rising CO readings or a failed combustion analysis at service
Before you order
- Confirm your boiler model and, where shown, the GC number on the data badge before ordering.
- Check the burner currently fitted against the number 60000288 to confirm whether the -01 replacement is the correct item.
- Check whether the burner gasket or seal needs renewing at the same time as the burner.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Burner |
|---|---|
| Appliance family | Clas HE EVO, E-Combi EVO 24, System |
Compliance
| Manufacturer part number (MPN) | 60000288-01 |
|---|---|
| Barcode / EAN | 3234090793505 |
| Commodity code | 8416 20 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 7625874827497, ARISTON60000288-01, ARISTON60000288-01, ARISTON60000288-01, 265075904395, 1579537 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| ARISTON ARISTON CLAS HE 24 FF | — | — | — | |
| ARISTON ARISTON CLAS HE 24 FF SYSTEM | — | — | — | |
| ARISTON ARISTON CLAS HE 24R | — | — | — | |
| ARISTON ARISTON COMBI A 24 MFFI | — | — | — | |
| ARISTON ARISTON E-COMBI 24 FF | — | — | — | |
| ARISTON ARISTON E-SYSTEM 24 | — | — | — | |
| ARISTON CLAS HE 24 FF NG UK (MAY 2007) | 47-116-51 | 47-116-51 | — | — |
| ARISTON CLAS HE 24 FF SYSTEM NG UK (MAY 2007) | 41-116-22 | 41-116-22 | — | — |
| ARISTON CLAS HE EVO 24 UK | 47-116-73 | 47-116-73 | — | — |
| ARISTON CLAS HE R 24 NG | 41-116-32 | 41-116-32 | — | — |
Showing 10 of 29 compatible appliances.
Fitment listings are a guide, not a guarantee. Plant-room assemblies get modified on site more often than not. Send us the GC number off the data badge and a photo of the existing valve and we will confirm before anything is dispatched.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
manual
ARISTON appliance manual — CLAS HE 24 FF NG UK (MAY 2007) (GC 47-116-51)
manualmanualARISTON appliance manual — CLAS HE 24 FF SYSTEM NG UK (MAY 2007) (GC 41-116-22)
manualmanualARISTON appliance manual — CLAS HE EVO 24 UK (GC 47-116-73), CLAS HE SYSTEM EVO 18 UK (GC 41-116-41), CLAS HE SYSTEM EVO 24 UK (GC 41-116-42)
manualmanualARISTON appliance manual — CLAS HE R 24 NG (GC 41-116-32)
manualmanualARISTON appliance manual — COMBI A 24 MFFI NG FROM APRIL 2006 (GC 47-116-44)
manualmanualARISTON appliance manual — E-COMBI 24 FF NG (UK) (GC 47-116-62), E-SYSTEM 24 NG (UK) (GC 41-116-34)
manualmanualARISTON appliance manual — E-COMBI EVO 24 FF UK (GC 47-116-68), E-SYSTEM EVO 24 UK (GC 41-116-39)
manualmanualARISTON appliance manual — GENUS HE 24 FF NG UK (APRIL 2007) (GC 47-116-54)
manualmanualARISTON appliance manual — GENUS HE 24 FF SYSTEM NG UK (MAY 2007) (GC 41-116-24)
manualNo technical questions yet for this part.
