Ariston
Ariston Air Pressure Switch 571653-01
Ariston 571653-01 air pressure switch rated at 96 Pa for specified Microsystem RFFI boiler serial ranges.
At a glance
- Also known as 1579911
£54.12
£45.10 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ariston 571653-01 is an air pressure switch rated at 96 Pa, used on Ariston Microsystem RFFI gas boilers. It monitors the pressure generated by the combustion fan and proves that airflow is established before the boiler is allowed to fire. It is fitted to appliances from the serial number ranges listed below.
Signs this part needs replacing
- Boiler locks out or fails to fire with the fan running normally
- Lockout occurs intermittently, often clearing on reset before returning
- Fan proving fault or air pressure fault indicated by the boiler controls
- No ignition sequence initiated despite a demand for heat
- Boiler cuts out shortly after firing and will not complete a run cycle
Before you order
- Confirm the appliance serial number falls within the range shown in the fit list, as earlier and later builds use different switches
- Check the model and edition of your Microsystem RFFI against the list above
- Verify the existing switch is rated at 96 Pa before ordering
- Inspect the sensing tubes and connections for blockage or leakage, as these can mimic a switch fault
Compliance
| Barcode / EAN | 3234090790597 |
|---|---|
| Alternative numbers | 1579911 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| ARISTON ARISTON MICROSYSTEM 21 RFFI - FROM SERIAL No 2320021100001 TO SERIAL No 2320030800001 | — | — | — | |
| ARISTON ARISTON MICROSYSTEM 28 RFFI - FROM SERIAL No 2320021100001 TO SERIAL No 2320030800001 | — | — | — | |
| ARISTON MICROSYSTEM 28 RFFI LPG EDITION 1 (AUG 2000) | 41-116-07 | 41-116-07 | — | — |
| ARISTON MICROSYSTEM 28 RFFI LPG EDITION 2 (JAN 2004) | 41-116-07 | 41-116-07 | — | — |
| ARISTON MICROSYSTEM 28 RFFI LPG EDITION 3 (SEPT 2004) | 41-116-07 | 41-116-07 | — | — |
| ARISTON MICROSYSTEM 28 RFFI NG EDITION 1 (AUG 2000) | 41-116-07 | 41-116-07 | — | — |
| ARISTON MICROSYSTEM 28 RFFI NG EDITION 2 (JAN 2004) | 41-116-07 | 41-116-07 | — | — |
| ARISTON MICROSYSTEM 28 RFFI NG EDITION 3 (SEPT 2004) | 41-116-07 | 41-116-07 | — | — |
