Main Front Insulation Combustion Chamber 5000537
Front combustion chamber insulation panel, part 5000537, for Main and Potterton gas boilers.
At a glance
- Also known as 1123232
£10.96
£9.13 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The front combustion chamber insulation panel, manufacturer part number 5000537, is a shaped insulating board that lines the front face of the combustion chamber. It is used on Main and Potterton gas boilers, where it protects the surrounding casing and components from the heat of combustion. The panel forms part of the boiler's thermal protection and must be intact for the appliance to operate safely.
Signs this part needs replacing
- Visible cracking, crazing or splitting of the insulation board
- Crumbling, flaking or powdery material breaking away from the panel
- Blackening or heavy heat scorching across the front face
- Insulation debris found loose inside the combustion chamber
- Panel distorted or no longer sitting flush against the chamber front
Before you order
- Confirm your boiler model against the fit list above before ordering
- Check whether the damaged insulation is the front panel or a rear or side panel
- Inspect the remaining insulation boards, as heat damage is often found on more than one panel
- Have the appliance model and serial plate details to hand when checking compatibility
Compliance
| GC number | 114-850 |
|---|---|
| Barcode / EAN | 5039177639008 |
| Alternative numbers | 1123232 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| MAIN MAIN HEATING ONLY 12 HE | 41-474-02 | 41-474-02 | — | — |
| MAIN MAIN HEATING ONLY 15 HE | 41-474-03 | 41-474-03 | — | — |
| MAIN MAIN HEATING ONLY 18 HE | 41-474-04 | 41-474-04 | — | — |
| MAIN MAIN HEATING ONLY 24 HE | 41-474-05 | 41-474-05 | — | — |
| MAIN MAIN HEATING ONLY 9 HE | 41-474-01 | 41-474-01 | — | — |
| POTTERTON PERFORMA HE 12 SL | 41-592-06 | 41-592-06 | — | — |
| POTTERTON PERFORMA HE 15 SL | 41-592-07 | 41-592-07 | — | — |
| POTTERTON PERFORMA HE 18 SL | 41-592-08 | 41-592-08 | — | — |
| POTTERTON PERFORMA HE 21 SL | 41-592-09 | 41-592-09 | — | — |
| POTTERTON PERFORMA HE 24 SL | 41-592-10 | 41-592-10 | — | — |
Showing 10 of 24 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
MAIN appliance manual — MAIN HEATING ONLY 12 HE (GC 41-474-02), MAIN HEATING ONLY 15 HE (GC 41-474-03), MAIN HEATING ONLY 18 HE (GC 41-474-04), MAIN HEATING ONLY 24 HE (GC 41-474-05), MAIN HEATING ONLY 9 HE (GC 41-474-01)
manualmanualPOTTERTON appliance manual — PERFORMA HE 12 SL (GC 41-592-06), PERFORMA HE 15 SL (GC 41-592-07), PERFORMA HE 18 SL (GC 41-592-08), PERFORMA HE 21 SL (GC 41-592-09), PERFORMA HE 24 SL (GC 41-592-10), PERFORMA HE 9 SL (GC 41-592-05)
manualmanualPOTTERTON appliance manual — SUPRIMA 100 L (GC 41-590-48), SUPRIMA 30 L (GC 41-590-42), SUPRIMA 40 L (GC 41-590-43), SUPRIMA 50 L (GC 41-590-44), SUPRIMA 60 L (GC 41-590-45), SUPRIMA 70 L (GC 41-590-46), SUPRIMA 80 L (GC 41-590-47)
manualmanualPOTTERTON appliance manual — SUPRIMA 30 HE (GC 41-075-35), SUPRIMA 40 HE (GC 41-075-36), SUPRIMA 50 HE (GC 41-075-37), SUPRIMA 60 HE (GC 41-075-38), SUPRIMA 70 HE (GC 41-075-39), SUPRIMA 80 HE (GC 41-075-40)
manualNo technical questions yet for this part.
