Ferroli Gasket - Electrode Assembly 35101570
Gasket for the electrode assembly on Ferroli Arena 20A, 20C, 30A and 30C gas boilers, sealing the electrode where it enters the combustion chamber.
At a glance
- Part type: gasket for the electrode assembly
- Appliance family: Ferroli Arena gas boilers
- Also known as 1210269
£2.04
£1.70 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ferroli 35101570 is a gasket for the electrode assembly used on Ferroli Arena gas boilers. It sits between the electrode assembly and the combustion chamber face, sealing the point where the electrode passes through the casing. Its job is to hold a gas-tight seal so combustion products cannot escape and air cannot be drawn in around the electrode.
Signs this part needs replacing
- Visible cracking, hardening or perishing of the gasket material
- Staining, soot tracking or moisture around the electrode entry point
- Combustion readings drifting or flue gas analysis failing to settle
- Ignition or flame detection faults traced to the electrode area
- Heat damage or distortion to the gasket face after servicing the electrode
Before you order
- Confirm the boiler model and the version code on the data badge against the fit list
- Check the condition of the electrode assembly itself, as the gasket is normally renewed with it
- Compare the old gasket profile and fixing arrangement with the new part before fitting
- Check the combustion chamber sealing face for damage that could prevent a gas-tight joint
Compliance
| GC number | E73-241 |
|---|---|
| Alternative numbers | FER35101570, 1210269 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| FERROLI ARENA 20A - 30R0434/0 (01/05/2000) | — | — | — | |
| FERROLI ARENA 20C - 30R0424/0 (01/05/2000) | — | — | — | |
| FERROLI ARENA 30A - 30R0434/0 (01/05/2000) | 41-267-15 | 41-267-15 | — | — |
| FERROLI ARENA 30A - 30R0434/0 (01/05/2001) | 47-267-15 | 47-267-15 | — | — |
| FERROLI ARENA 30C - 30R0424/0 (01/05/2000) | 47-267-25 | 47-267-25 | — | — |
| FERROLI ARENA 30C - 30R0424/0 (01/05/2001) | 47-267-25 | 47-267-25 | — | — |
