Alpha
Alpha 3.022793 InTEC Grundfos 59200278 Pump Head Motor
At a glance
- Part type: Pump head motor
- Also known as 1258333, ALPHA3.022793
£217.14
£180.95 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Alpha 3.022793 is a replacement pump head motor for Alpha InTEC and EcoInTEC condensing boilers. It forms the motor and impeller section of the boiler's circulating pump, which moves heating water around the primary circuit. The head mounts onto the pump body inside the appliance and is driven whenever the boiler calls for heat.
Signs this part needs replacing
- The pump runs noisily, humming or grinding when the boiler fires
- Radiators stay cold or heat unevenly while the boiler is running
- The boiler locks out or overheats shortly after ignition
- The flow pipe runs hot but the return stays cold, indicating poor circulation
- The pump head does not run at all when there is a demand for heat
Before you order
- Check the boiler model and serial number against the compatibility list to confirm the correct fitment
- Compare the part number on the existing pump head with 3.022793 and the alternative numbers listed
- Check whether the pump gasket or seal needs replacing at the same time
- Any work inside the boiler casing should be carried out by a competent engineer
Mechanical
| Part type | Pump head motor |
|---|---|
| Appliance family | InTEC / EcoInTEC |
Compliance
| Manufacturer part number (MPN) | 3.022793 |
|---|---|
| Commodity code | 8413 91 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | ALPHA3.022793, 1258333 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| ALPHA ALPHA ECO | — | — | — | |
| ALPHA ALPHA ECO BOILER | — | — | — | |
| ALPHA ALPHA INTEC 12S | — | — | — | |
| ALPHA ALPHA INTEC 12S LPG | — | — | — | |
| ALPHA ALPHA INTEC 18S | — | — | — | |
| ALPHA ALPHA INTEC 18S LPG | — | — | — | |
| ALPHA ALPHA INTEC 24X | — | — | — | |
| ALPHA ALPHA INTEC 26C | — | — | — | |
| ALPHA ALPHA INTEC 26C LPG | — | — | — | |
| ALPHA ALPHA INTEC 28S | — | — | — |
Showing 10 of 41 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
ALPHA appliance manual — ALPHA ECO BOILER
manualmanualALPHA appliance manual — InTEC 12S (GC 41-532-22), InTEC 12S (LPG) (GC 41-532-25), InTEC 18S (GC 41-532-23), InTEC 18S (LPG) (GC 41-532-26), InTEC 28S (GC 41-532-24), InTEC 28S (LPG) (GC 41-532-27)
manualmanualALPHA appliance manual — InTEC 24X (GC 47-532-45), InTEC 24X (LPG) (GC 47-532-52), InTEC 26C (GC 47-532-47), InTEC 26C (LPG) (GC 47-532-54), InTEC 28X (GC 47-532-46), InTEC 28X (LPG) (GC 47-532-53), InTEC 30C (GC 47-532-48), InTEC 30C (LPG) (GC 47-532-55), InTEC 34C (GC 47-532-49), InTEC 34C (LPG) (GC 47-532-56)
manualmanualALPHA appliance manual — InTEC 30GS (GC 47-532-50), InTEC 30GS (LPG) (GC 47-532-57), InTEC 40GS (GC 47-532-51), InTEC 40GS (LPG) (GC 47-532-58)
