Ideal Wiring Harness Mains 179152
Mains wiring harness for Ideal Vogue Max System and Ideal Commercial boilers, part 179152, alternative number 1777743.
At a glance
- Part type: Wiring harness (mains)
- Also known as 1777743
£45.56
£37.97 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 179152 is a mains wiring harness — the lead and connector assembly that carries mains power into the boiler's control and PCB area. It is supplied by Ideal for the Vogue Max System range and for Ideal Commercial appliances. The harness plugs into the boiler's electrical connections, so a damaged or loose one interrupts the supply to the controls.
Signs this part needs replacing
- No power at the boiler controls even though the supply is live at the isolator
- Intermittent shutdowns or a flickering display traced back to a loose mains plug
- Scorched, brittle or discoloured insulation along the harness
- Burned or corroded terminals inside the connector block
- RCD tripping when the boiler is switched on
Before you order
- Match the GC number on the appliance data badge against the compatibility list; the Vogue Max System outputs are listed separately.
- The alternative number 1777743 identifies the same harness.
- Isolate the electrical supply at the double-pole isolator before removing the old harness.
Mechanical
| Part type | Cables, Leads & Wiring Harnesses |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 179152 |
|---|---|
| Barcode / EAN | 5022141791529 |
| Commodity code | 8544 42 90 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1777743 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL VOGUE MAX SYSTEM 15 | 41-796-22 | 41-796-22 | — | — |
| IDEAL VOGUE MAX SYSTEM 18 | 41-796-23 | 41-796-23 | — | — |
| IDEAL VOGUE MAX SYSTEM 26 | 41-796-24 | 41-796-24 | — | — |
| IDEAL VOGUE MAX SYSTEM 32 | 41-796-25 | 41-796-25 | — | — |
| IDEAL VOGUE S15 GEN2 | 41-750-88 | 41-750-88 | — | — |
| IDEAL VOGUE S15 IE GEN2 | 41-750-97 | 41-750-97 | — | — |
| IDEAL VOGUE S18 GEN2 | 41-750-89 | 41-750-89 | — | — |
| IDEAL VOGUE S18 IE GEN2 | 41-750-98 | 41-750-98 | — | — |
| IDEAL VOGUE S26 GEN2 | 41-750-90 | 41-750-90 | — | — |
| IDEAL VOGUE S26 IE GEN2 | 41-750-99 | 41-750-99 | — | — |
Showing 10 of 13 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL appliance manual — VOGUE MAX SYSTEM 15 (GC 41-796-22), VOGUE MAX SYSTEM 18 (GC 41-796-23), VOGUE MAX SYSTEM 26 (GC 41-796-24), VOGUE MAX SYSTEM 32 (GC 41-796-25)
manualmanualIDEAL appliance manual — VOGUE S15 GEN2 (GC 41-750-88), VOGUE S18 GEN2 (GC 41-750-89), VOGUE S26 GEN2 (GC 41-750-90), VOGUE S32 GEN2 (GC 41-750-91)
manualmanualIDEAL appliance manual — VOGUE S15 IE GEN2 (GC 41-750-97), VOGUE S18 IE GEN2 (GC 41-750-98), VOGUE S26 IE GEN2 (GC 41-750-99), VOGUE S32 IE GEN2 (GC 41-796-01)
manualNo technical questions yet for this part.
