Ideal Wiring Harness Mechanical Timer 179078

The Ideal 179078 is a wiring harness that links the mechanical timer to the boiler's control circuit. It is manufactured by Ideal as a spare for the Independent and Independent + Combi range, where it carries the switching signals that let the timer bring the appliance on and off to schedule. The harness is supplied as a complete lead assembly, so a damaged or intermittent connection at the timer can be renewed without rewiring the plug by hand.

• The mechanical timer runs but the boiler does not respond to the switched periods.
• Heating or hot water comes on outside the set times, or drops out partway through a period.
• The timer works only when the harness is moved or the plug is pressed into place.
• Visible damage to the lead: chafed insulation, a scorched or discoloured connector, or a broken retaining clip.
• Intermittent faults that disappear when the harness is reseated, then return after a few cycles.

• This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
• Match the GC number on the appliance data badge against the compatibility list before ordering, as the same model name can appear with more than one GC number.
• Confirm the harness connector pattern against the timer already fitted, and quote 1777740 if your parts list uses the alternative number.
