Ideal PCB Kit BCC Combi 24 176665
Ideal 176665 printed circuit board kit for BCC Combi 24 and other Ideal combi models, controlling ignition, fan and pump sequencing.
At a glance
- Part type: Printed circuit board kit
- Appliance family: BCC Combi 24
- Also known as 1781952
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 176665 is a printed circuit board (PCB) kit manufactured by Ideal for its combi boiler range. It is the control board assembly that governs ignition sequencing, fan and pump operation, temperature regulation and fault monitoring. The kit is listed for the BCC Combi 24 platform and is shared across a number of Ideal combi and commercial appliances.
Signs this part needs replacing
- Boiler fails to fire, or repeatedly goes to lockout with no mechanical cause found
- Blank display, dead indicator LEDs or controls that do not respond
- Intermittent shutdowns or recurring fault codes that clear and return
- Fan, pump or ignition sequence does not start when demand is called
- Visible scorching, burnt tracks, swollen components or a blown board fuse
Before you order
- Confirm the appliance model and GC number against the compatibility list, as board revisions differ between models.
- Check the board currently fitted against part number 176665 and alternative number 1781952 before ordering.
- Isolate the electrical supply at the fused spur before removing or refitting the board.
- Photograph the existing wiring and connector positions before disconnecting the old board.
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Appliance family | BCC Combi 24 |
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 176665 |
|---|---|
| Barcode / EAN | 5022141766657 |
| Commodity code | 8537 10 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781952 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL CLASSIC COMBI 24 | 47-349-07 | 47-349-07 | — | — |
| IDEAL ESPRIT ECO 24 | 47-348-91 | 47-348-91 | — | — |
| IDEAL EXCLUSIVE 24 COMBI | 47-349-41 | 47-349-41 | — | — |
| IDEAL INSTINCT 24 | 47-349-09 | 47-349-09 | — | — |
| IDEAL MORCO GB24 | — | — | — | |
| IDEAL MORCO GB24 SERIES II | — | — | — | |
| IDEAL PROCOMBI EXCLUSIVE 24 | 47-348-79 | 47-348-79 | — | — |
| IDEAL iCOMBI 24 | 47-348-82 | 47-348-82 | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL appliance manual — CLASSIC COMBI 24 (GC 47-349-07)
manualmanualIDEAL appliance manual — ESPRIT ECO 24 (GC 47-348-91)
manualmanualIDEAL appliance manual — EXCLUSIVE 24 COMBI (GC 47-349-41)
manualmanualIDEAL appliance manual — INSTINCT 24 (GC 47-349-09)
manualmanualIDEAL appliance manual — PROCOMBI EXCLUSIVE 24 (GC 47-348-79)
manualmanualIDEAL appliance manual — iCOMBI 24 (GC 47-348-82)
manualNo technical questions yet for this part.
