Ideal
Ideal BCC Kit 176420
BCC kit (BCC card) PCB spare for Ideal Commercial Evomax 30 boilers, part 176420, GC 41-750-33A.
At a glance
- Part type: BCC kit (BCC card)
- Appliance family: Ideal Commercial Evomax
- Also known as 1781892
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 176420 is a BCC kit supplied as a printed circuit board spare for Ideal Commercial appliances. It sits within the control electronics of the boiler, where the board handles the appliance's control and sequencing functions. The kit is listed by Ideal under the spare part type Printed Circuit Boards (PCB) and is used on the Evomax 30 commercial range.
Signs this part needs replacing
- The boiler locks out repeatedly with no obvious ignition or water-side cause
- The display or control panel is dead, blank or unresponsive
- Fault codes appear that point to the control board rather than a sensor or fan
- The appliance ignores demand from the room thermostat or external controls
- Visible scorching, discoloured tracks or swollen components on the existing board
Before you order
- Check the GC number on the appliance data plate against 41-750-33A before ordering
- Confirm the board currently fitted matches the layout and connections of the 176420 kit
- Note the alternative number 1781892, which may appear on older Ideal documentation for the same item
- Isolate the electrical supply to the appliance before removing or fitting any control board
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 176420 |
|---|---|
| GC number | 41-750-33A |
| Barcode / EAN | 5022141764202 |
| Commodity code | 8537 10 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781892 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL EVOMAX 30 | 41-750-33A | 41-750-33A | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
