Ideal Printed Circuit Board Kit BCC Combi Plus 24 176402
Ideal 176402 printed circuit board kit for Logic+ Combi 24 boilers, carrying the control and programmer electronics. GC 47-348-65.
At a glance
- Part type: Printed circuit board (PCB)
- Also known as 1781882
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 176402 is a printed circuit board kit for Ideal Logic+ Combi 24 appliances. It carries the control electronics that govern boiler operation, including the programmer function — the clock or timer interface that sets when central heating and hot water are fired and lets the user maintain the room temperature. It is supplied as an Ideal Spares component under part number 176402.
Signs this part needs replacing
- The boiler does not respond to a heating or hot water demand
- The programmer or clock loses time, or stored settings are not held
- The display is blank, flickering or showing fault codes
- Repeated lockouts or the appliance needing frequent resets
- No ignition sequence runs even though the appliance has power
Before you order
- Check the appliance GC number and model against the compatibility list; the 176402 is listed for Logic+ Combi 24 variants.
- Confirm the part number on the existing board and cross-check it against alternative number 1781882.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 176402 |
|---|---|
| GC number | 47-348-65 |
| Barcode / EAN | 5022141764028 |
| Commodity code | 8537 10 98 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781882 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL IDEAL : LOGIC + COMBI 24 | — | — | — | |
| IDEAL LOGIC + COMBI 24 | 47-348-65 | 47-348-65 | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
