Ideal Chip Card Kit Combi 35 Prefix Ace 176401
Ideal chip card kit (PCB) for Combi 35 Prefix Ace boilers, part 176401, the central control board that regulates boiler processes.
At a glance
- Part type: Printed circuit board (chip card kit)
- Also known as 1781880
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal chip card kit is a printed circuit board assembly used as the central control of the boiler. It reads inputs from the appliance's sensors, switches and thermostats, and uses them to monitor and regulate every process that takes place during operation. This kit sits within the printed circuit board section of the Ideal spares range and is specified for the Combi 35 Prefix Ace family of appliances.
Signs this part needs replacing
- The boiler fails to fire or does not respond to a call for heat.
- The display is blank, flickering or showing fault codes.
- The appliance runs erratically, with heating or hot water cutting in and out.
- Sensors, switches and thermostats appear to have no effect on boiler behaviour.
- The board shows visible signs of damage, moisture ingress or burnt components.
Before you order
- Check the boiler's GC number and serial plate against the compatibility list to confirm the correct board for your model.
- Confirm the alternative number 1781880 where a board has been replaced previously.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 176401 |
|---|---|
| Barcode / EAN | 5022141764011 |
| Commodity code | 8537 10 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781880 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL EXCLUSIVE 35 COMBI | 47-349-43 | 47-349-43 | — | — |
| IDEAL IDEAL : INDEPENDENT C35 | — | — | — | |
| IDEAL IDEAL : LOGIC COMBI 35 | — | — | — | |
| IDEAL IDEAL : LOGIC COMBI E 35 | — | — | — | |
| IDEAL IDEAL : LOGIC COMBI ES 35 | — | — | — | |
| IDEAL IDEAL : LOGIC COMBI ESP 35 | — | — | — | |
| IDEAL INDEPENDENT C35 | 47-348-70 | 47-348-70 | — | — |
| IDEAL INDEPENDENT PLUS C35 | 47-348-87 | 47-348-87 | — | — |
| IDEAL INSTINCT 35 | 47-349-11 | 47-349-11 | — | — |
| IDEAL LOGIC COMBI 35 | 47-348-58 | 47-348-58 | — | — |
Showing 10 of 17 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL appliance manual — EXCLUSIVE 35 COMBI (GC 47-349-43)
manualmanualIDEAL appliance manual — INDEPENDENT C35 (GC 47-348-70)
manualmanualIDEAL appliance manual — INDEPENDENT PLUS C35 (GC 47-348-87)
manualmanualIDEAL appliance manual — INSTINCT 35 (GC 47-349-11)
manualmanualIDEAL appliance manual — LOGIC COMBI 35 (GC 47-348-58)
manualmanualIDEAL appliance manual — LOGIC COMBI E 35 (GC 47-348-90)
manualmanualIDEAL appliance manual — LOGIC COMBI ES 35 (GC 47-349-03)
manualmanualIDEAL appliance manual — PROCOMBI EXCLUSIVE 35 (GC 47-348-81)
manualmanualIDEAL appliance manual — ZANUSSI ULTRA COMBI 35 (GC 47-002-02)
manualmanualIDEAL appliance manual — iCOMBI 35 (GC 47-348-84)
manualNo technical questions yet for this part.
