Ideal Inspection Cover Kit 100/150kW 176344
Ideal 176344 inspection cover kit for Evomax 100 and 150 and Instinct Heat 150 commercial boilers, forming part of the casing assembly.
At a glance
- Part type: Casing assembly
- Also known as 1782284
£14.87
£12.39 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 176344 is an inspection cover kit that forms part of the casing assembly on Ideal Commercial boilers. It provides the removable panel over the appliance's inspection opening, closing the aperture during normal running while allowing an engineer to gain access for service and combustion checks. The kit is listed for 100kW and 150kW output models in the Evomax and Instinct Heat ranges.
Signs this part needs replacing
- The cover is cracked, warped or visibly distorted
- Fixings or fasteners are corroded, seized or missing so the panel will not seat correctly
- The cover no longer sits flush against the casing, leaving a gap around the inspection aperture
- Discolouration or heat marking around the cover or its mounting points
- The cover has been removed during servicing and not refitted
Before you order
- Check the GC number on the appliance data badge against the compatibility list below before ordering
- Confirm the number on the existing component matches 176344 or the alternative number 1782284
- Check the condition of the existing fixings, as these are reused when the new cover is fitted
- Confirm the appliance is a 100kW or 150kW output model, as the kit is listed for these ratings
Mechanical
| Part type | Casing assembly |
|---|
Compliance
| Manufacturer part number (MPN) | 176344 |
|---|---|
| Barcode / EAN | 5022141763441 |
| Commodity code | 8403 90 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1782284 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL EVOMAX 100 | 41-750-37A | 41-750-37A | — | — |
| IDEAL COMMERCIAL EVOMAX 150 | 41-750-39A | 41-750-39A | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — | |
| IDEAL COMMERCIAL INSTINCT HEAT 150 | — | — | — |
