Ideal Printed Circuit Board Logic Code Combi 33 176153
Ideal 176153 printed circuit board kit for Logic Code Combi 33 and ES33 boilers, controlling ignition, fan and pump sequencing.
At a glance
- Part type: Printed circuit boards (PCB)
- Appliance family: Logic Code Combi
- Also known as 1781830
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 176153 is a printed circuit board (PCB) kit supplied for the Logic Code Combi range of gas boilers. It is the control board that governs the boiler's operating sequence, handling ignition, fan and pump control along with the temperature and safety inputs that keep the appliance running within its design parameters. The board is listed under Ideal's printed circuit board spare part category and is also referenced by the alternative number 1781830.
Signs this part needs replacing
- The boiler fails to run through its start-up sequence, with no ignition or no fan operation.
- The display is blank, shows scrambled characters, or the boiler will not respond to demand.
- Repeated lockouts or fault codes that clear temporarily and then return.
- The pump or fan runs continuously, or does not run at all, when a demand is present.
- Intermittent operation that changes with temperature or after the board has been powered for a while.
Before you order
- Check the GC number on the appliance data badge against the numbers listed above before ordering.
- Confirm the board currently fitted carries the number 176153 or the alternative number 1781830.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Appliance family | Logic Code Combi |
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 176153 |
|---|---|
| GC number | 47-349-05 |
| Barcode / EAN | 5022141761539 |
| Commodity code | 8537 10 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781830 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL IDEAL : LOGIC CODE COMBI 33 | — | — | — | |
| IDEAL IDEAL : LOGIC CODE COMBI ES33 | — | — | — | |
| IDEAL LOGIC CODE COMBI 33 | 47-348-75 | 47-348-75 | — | — |
| IDEAL LOGIC CODE COMBI ES33 | 47-349-05 | 47-349-05 | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
