Ideal Condensate Sump iMax Plus 6 Mod 176096

The Ideal 176096 is a condensate sump manufactured for Ideal commercial boilers. It sits at the base of the heat exchanger on iMax Plus 1 and iMax Plus 2 appliances built in 6-module configuration, where it collects the condensate formed during combustion and routes it towards the condensate trap and drain. The sump is a serviceable component, so it can be replaced when the original has cracked, distorted or started to leak.

• Water or condensate pooling around the base of the boiler or inside the casing
• Visible cracking, crazing or distortion of the sump body
• Damp staining, corrosion or scale trails on and around the sump
• Condensate overflowing rather than draining away, or the trap failing to hold its water seal
• Repeated nuisance lockouts or fault codes linked to condensate disposal

• Check the appliance model and serial number against the compatibility list to confirm the sump is the correct pattern for your iMax Plus unit.
• Compare the number on the existing component with 176096 and 95211561 before ordering.
• Confirm the module count of the boiler, as the 6-module version is specific to that build.
