Ideal Printed Circuit Board Logic System 30ie 175959
Ideal 175959 printed circuit board for Logic System 30ie and Logic Heat 30 boilers, controlling ignition, sensors and safety routines.
At a glance
- Part type: Printed circuit board (Kit BCC Card)
- Appliance family: Ideal Logic, Logic + Heat and Logic System
- Also known as 1781630
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 175959 is a printed circuit board (PCB) supplied as a Kit BCC Card for the Ideal Logic range. It is the control board that runs the boiler's operating sequence, reading inputs from the appliance's sensors and initiating every action the boiler takes, from firing to shutdown. The board is programmed with the routines specific to the models it serves, so the correct variant must be matched to the appliance.
Signs this part needs replacing
- The boiler goes to lockout or fails to fire when there is a call for heat
- No display, blank screen or unlit status indicators on the control panel
- Repeated or intermittent fault codes that clear and return without an obvious cause
- The fan, pump or ignition sequence does not start despite demand and a live supply
- Erratic behaviour such as the boiler running outside the set parameters or responding slowly to controls
Before you order
- Confirm the GC number on the appliance data badge against the numbers listed above, as the board is programmed for specific models
- Check the existing board's part number and cross-reference it with 175959 and 1781630 before ordering
- Inspect the wiring harness, plugs and any gaskets or seals disturbed during removal and replace them if damaged
Mechanical
| Part type | Printed circuit board |
|---|---|
| Appliance family | Ideal Logic, Logic + Heat, Logic System |
Compliance
| Manufacturer part number (MPN) | 175959 |
|---|---|
| GC number | 41-750-47 |
| Barcode / EAN | 5022141759598 |
| Commodity code | 8537 10 00 00 |
| GPC classification | Electronic Circuit Accessories |
| Alternative numbers | 1781630 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL IDEAL : LOGIC + HEAT 30 | — | — | — | |
| IDEAL IDEAL : LOGIC HEAT 30 | — | — | — | |
| IDEAL IDEAL : LOGIC SYSTEM 30IE | — | — | — | |
| IDEAL LOGIC + HEAT 30 | 41-750-22 | 41-750-22 | — | — |
| IDEAL LOGIC HEAT 30 | 41-409-96 | 41-409-96 | — | — |
| IDEAL LOGIC SYSTEM 30IE | 41-750-47 | 41-750-47 | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
