Ideal Printed Circuit Board BCC Card Logic 175958
Ideal 175958 PCB kit (BCC card) for Logic Heat 24 and Logic System 24IE boilers, controlling boiler sequence and safety functions.
At a glance
- Part type: Printed circuit board (PCB)
- Also known as 1781628
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 175958 is a printed circuit board kit supplied as a BCC card for the Ideal Logic and Logic+ appliance families. It sits within the boiler's control assembly and carries out the sequencing and monitoring duties that keep combustion, heating and hot water operation running in the correct order. The board is manufactured for Ideal and listed under the Ideal Spares brand.
Signs this part needs replacing
- The boiler fails to fire or does not respond to a call for heat or hot water
- The display is blank, flickering or showing repeated fault codes
- The appliance locks out intermittently and needs resetting to run again
- Fan, pump or ignition sequence behaves erratically with no obvious mechanical cause
- Visible heat damage, corrosion or tracking on the board itself
Before you order
- Confirm the GC number on the appliance data badge against the list above before ordering
- Check the existing board's part number and cross-reference it with 1781628
- Inspect the board connector plugs and harness for damage while the appliance is open
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 175958 |
|---|---|
| GC number | 41-750-21, 41-409-95, 41-750-46 |
| Barcode / EAN | 5022141759581 |
| Commodity code | 8537 10 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781628 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL IDEAL : LOGIC + HEAT 24 | — | — | — | |
| IDEAL IDEAL : LOGIC HEAT 24 | — | — | — | |
| IDEAL IDEAL : LOGIC SYSTEM 24IE | — | — | — | |
| IDEAL LOGIC + HEAT 24 | 41-750-21 | 41-750-21 | — | — |
| IDEAL LOGIC HEAT 24 | 41-409-95 | 41-409-95 | — | — |
| IDEAL LOGIC SYSTEM 24IE | 41-750-46 | 41-750-46 | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
