Ideal Printed Circuit Board BCC Combi Plus 35 175938
Ideal 175938 printed circuit board kit for Logic+ Combi 35 and Ideal Commercial appliances, controlling ignition, fan and pump sequencing.
At a glance
- Part type: Printed circuit board (PCB)
- Appliance family: Ideal Logic + Combi and Ideal Commercial
- Also known as 1781614
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£34.54
£28.78 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 175938 is a printed circuit board kit supplied for the Logic+ Combi 35 and associated Ideal Commercial appliance range. The board is the control centre of the boiler, running the ignition sequence, fan and pump operation, and the safety monitoring that keeps combustion within its set limits. It is supplied as a kit rather than a bare board, so the replacement carries the components needed to restore control function on the appliance it is listed against.
Signs this part needs replacing
- The boiler fails to fire, with no ignition sequence starting when there is a call for heat.
- The display is blank, flickering or showing fault codes that clear and return.
- The fan or pump does not run when the appliance is switched on.
- The boiler locks out intermittently, often after running for a short period.
- Controls respond erratically, or the appliance behaves differently from the settings selected.
Before you order
- Check the GC number on the appliance data badge against 47-348-67 to confirm the board is correct for your model.
- Confirm the existing board carries the number 175938 or the alternative number 1781614 before ordering.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Printed Circuit Boards (PCB) |
|---|---|
| Appliance family | Ideal Logic + Combi / Ideal Commercial |
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 175938 |
|---|---|
| GC number | 47-348-67 |
| Barcode / EAN | 5022141759383 |
| Commodity code | 8537 10 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1781614 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL IDEAL : LOGIC + COMBI 35 | — | — | — | |
| IDEAL LOGIC + COMBI 35 | 47-348-67 | 47-348-67 | — | — |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
