Ideal Burner Harness 175020
Ideal burner harness 175020 (200008095) for Commercial Concord ESi boilers, linking the burner to the appliance control system.
At a glance
- Part type: Wiring harness (burner)
- Appliance family: Ideal Commercial Concord ESi
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£521.65
£434.71 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal burner harness, part 175020, is a wiring assembly that connects the burner to the control system on Ideal Commercial Concord ESi boilers. It carries the electrical supply and the ignition and flame-sensing signals the burner needs to operate. Supplied as a complete assembly with its connectors fitted, it can be replaced as a single unit during a repair.
Signs this part needs replacing
- The burner fails to light, or lights intermittently and then drops out
- Lockout or ignition fault codes appear on the boiler controls
- Insulation on the harness is chafed, brittle or heat-damaged
- Connector pins at the burner or control plug are loose, corroded or burnt
- Continuity faults are traced along the harness during fault-finding
Before you order
- Confirm the boiler model and GC number against the compatibility list before ordering
- Check that the connectors and pin count on the existing harness match the replacement
- Isolate the electrical supply and follow the manufacturer's instructions before fitting
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Wiring harness (burner) |
|---|---|
| Appliance family | Ideal Commercial Concord ESi |
Compliance
| Manufacturer part number (MPN) | 175020 |
|---|---|
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD ESi 140 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 160 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 180 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 200 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 220 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 260 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 300 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 340 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 380 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
