Ideal User Control PCB Evo HE 173160
Ideal 173160 user control printed circuit board for Evo HE boilers, carrying the appliance's user interface and control electronics.
At a glance
- Part type: Printed circuit board (user controls)
- Appliance family: Evo HE
- Also known as 1179305
£144.25
£120.21 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 173160 is a user control printed circuit board for the Ideal Evo HE range of domestic gas boilers. It carries the control electronics and user interface for the appliance, handling the signals that pass between the front panel controls and the boiler's main board. It is supplied as a board-level component and is listed by Ideal under the printed circuit board part type.
Signs this part needs replacing
- The boiler does not respond when the user controls are operated
- Display or indicator behaviour is erratic, blank or stuck
- The appliance runs intermittently or drops out during a demand for heat or hot water
- Visible damage on the board, such as scorching, discoloured tracks or swollen components
- Repeated lockouts that clear temporarily after the controls are disturbed
Before you order
- Confirm the appliance model and GC number against the compatibility list before ordering, as the Evo HE range uses more than one board variant
- Check the existing board for its printed part number and compare it with 173160
- Isolate the electrical supply to the boiler before removing or refitting the control panel
Mechanical
| Part type | Printed circuit board |
|---|---|
| Appliance family | Evo HE |
Compliance
| Manufacturer part number (MPN) | 173160 |
|---|---|
| Barcode / EAN | 5022141731600 |
| Commodity code | 8537 10 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1179305 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL EVO HE H12 | 41-397-96 | 41-397-96 | — | — |
| IDEAL EVO HE H16 | 41-397-86 | 41-397-86 | — | — |
| IDEAL EVO HE H19 | 41-397-93 | 41-397-93 | — | — |
| IDEAL EVO HE H22 | 41-397-94 | 41-397-94 | — | — |
| IDEAL IDEAL : EVO HE H16 | — | — | — | |
| IDEAL IDEAL : EVO HE H19 | — | — | — | |
| IDEAL IDEAL : EVO HE H22 | — | — | — | |
| IDEAL IDEAL : ISTOR HE260 | — | — | — | |
| IDEAL IDEAL : ISTOR HE325 | — | — | — | |
| IDEAL ISTOR HE260 | 41-394-13 | 41-394-13 | — | — |
Showing 10 of 12 compatible appliances.
