Ideal Control Module Fuse W45/W60/W80 & P 172663
Ideal 172663 control module fuses for Ideal Commercial Imax W45, W60, W80 and P series boilers, protecting the control module circuits.
At a glance
- Part type: Control module fuses
- Also known as 1178989
£11.14
£9.28 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 172663 is a set of control module fuses supplied for Ideal Commercial Imax W series boilers. The fuses sit in the control module circuit and protect the board and its connected components from overcurrent damage, blowing to isolate a fault before it reaches the electronics. They are a service item rather than a gas-carrying component.
Signs this part needs replacing
- The boiler is completely dead with no display or panel illumination
- No response when heating or hot water is called for
- The control module fuse blows again immediately after replacement, pointing to a fault further down the circuit
- Intermittent shutdowns or lockouts with no consistent fault code
- Visible scorching, blackening or a broken element on the fuse itself
Before you order
- Check the GC number on the appliance data badge against the compatibility list to confirm the model
- Confirm the existing fuse or control module is marked 172663
- 1178989 is an alternative number used for this part
- This is listed as a non-gas part, so no gas-carrying connections are involved in the swap
Mechanical
| Part type | Control Box, Panels And Accessories |
|---|---|
| Appliance family | Imax W45, W60, W80 and P |
Compliance
| Manufacturer part number (MPN) | 172663 |
|---|---|
| Barcode / EAN | 5022141726637 |
| Commodity code | 8536 10 10 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1178989 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — | |
| IDEAL COMMERCIAL IMAX W100 | — | — | — | |
| IDEAL COMMERCIAL IMAX W100P - PROPANE | — | — | — | |
| IDEAL COMMERCIAL IMAX W45 | 41-397-97 | 41-397-97 | — | — |
| IDEAL COMMERCIAL IMAX W45P - PROPANE | 41-399-01 | 41-399-01 | — | — |
| IDEAL COMMERCIAL IMAX W60 | 41-397-98 | 41-397-98 | — | — |
| IDEAL COMMERCIAL IMAX W60P - PROPANE | 41-399-02 | 41-399-02 | — | — |
| IDEAL COMMERCIAL IMAX W80 | 41-397-99 | 41-397-99 | — | — |
| IDEAL COMMERCIAL IMAX W80P - PROPANE | 41-399-03 | 41-399-03 | — | — |
| IDEAL COMMERCIAL IMAX XTRA E120 | — | — | — |
Showing 10 of 29 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL COMMERCIAL appliance manual — IMAX W45 (GC 41-397-97), IMAX W45P - PROPANE (GC 41-399-01), IMAX W60 (GC 41-397-98), IMAX W60P - PROPANE (GC 41-399-02), IMAX W80 (GC 41-397-99), IMAX W80P - PROPANE (GC 41-399-03)
manualmanualIDEAL COMMERCIAL appliance manual — IMAX XTRA E120, IMAX XTRA E160, IMAX XTRA E200, IMAX XTRA E240, IMAX XTRA E280, IMAX XTRA E80
manualmanualIDEAL COMMERCIAL appliance manual — IMAX XTRA E320, IMAX XTRA E400, IMAX XTRA E480, IMAX XTRA E560
manualmanualIDEAL COMMERCIAL appliance manual — IMAX XTRA F120, IMAX XTRA F160, IMAX XTRA F200, IMAX XTRA F240, IMAX XTRA F280, IMAX XTRA F80
manualNo technical questions yet for this part.
