Ideal
Ideal Relay W45 W60 W80 P 172658
Ideal 172658 relay for Ideal Commercial Imax W45, W60, W80 and P appliances, switching electrical loads on the control circuit.
At a glance
- Part type: Relay
- Also known as 1178985
£90.37
£75.31 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 172658 is a relay supplied as a spare for Ideal Commercial appliances. It sits on the appliance's electrical control circuit and switches the current that feeds a downstream component, such as the fan, pump or ignition circuit, when the control board signals a demand. It is an electrical accessory rather than a gas-carrying part, and it is listed against the Imax W45, W60, W80 and propane (P) variants.
Signs this part needs replacing
- The appliance does not fire or does not respond to a call for heat
- A switched component such as the fan or pump fails to run when demanded
- Intermittent operation, with the appliance running correctly on some cycles and not others
- Repeated lockouts or fault codes relating to the fan or ignition circuit
- Audible clicking from the control area with no follow-on action from the component it should be switching
Before you order
- Check the GC number on the appliance data badge against the numbers listed above
- Confirm the exact model variant, including propane (P) versions, before ordering
- Match the part number 172658 or the alternative number 1178985 to the relay being replaced
- Inspect the wiring and connectors at the relay position, as loose or damaged terminals can mimic a failed relay
Mechanical
| Part type | Electrical Accessories |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 172658 |
|---|---|
| GC number | 41-399-03 |
| Barcode / EAN | 5022141726583 |
| Commodity code | 8536 49 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1178985 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — | |
| IDEAL COMMERCIAL IMAX W100 | — | — | — | |
| IDEAL COMMERCIAL IMAX W100P - PROPANE | — | — | — | |
| IDEAL COMMERCIAL IMAX W45 | 41-397-97 | 41-397-97 | — | — |
| IDEAL COMMERCIAL IMAX W45P - PROPANE | 41-399-01 | 41-399-01 | — | — |
| IDEAL COMMERCIAL IMAX W60 | 41-397-98 | 41-397-98 | — | — |
| IDEAL COMMERCIAL IMAX W60P - PROPANE | 41-399-02 | 41-399-02 | — | — |
| IDEAL COMMERCIAL IMAX W80 | 41-397-99 | 41-397-99 | — | — |
| IDEAL COMMERCIAL IMAX W80P - PROPANE | 41-399-03 | 41-399-03 | — | — |
| IDEAL COMMERCIAL IMAX XTRA E120 | — | — | — |
Showing 10 of 29 compatible appliances.
