Ideal Inspection Cover Assembly W45-W60 & P 172629
Ideal 172629 inspection cover assembly for Imax W45, W45P, W60 and W60P commercial boilers, covering the inspection opening on the casing.
At a glance
- Part type: Casing assembly (inspection cover)
- Appliance family: Imax W45 / W60 series
- Also known as 1178959
£80.83
£67.36 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 172629 is an inspection cover assembly for Ideal Commercial Imax series boilers. It forms the removable panel over the inspection opening on the appliance casing, allowing the heat exchanger and combustion area to be viewed and serviced without stripping the full casing. The assembly is supplied as a complete cover unit for the W45, W45P, W60 and W60P models.
Signs this part needs replacing
- The cover is cracked, distorted or corroded around the fixing points.
- The panel no longer seats correctly, leaving a gap at the inspection opening.
- Fixings or mounting points on the cover are stripped or broken.
- The cover has been removed and not refitted, or has been lost during servicing.
- Combustion readings are inconsistent because the casing seal at the inspection opening is compromised.
Before you order
- Confirm the appliance model and GC number against the compatibility list, as the W45, W45P, W60 and W60P variants use different GC references.
- Check the existing cover and its fixings before ordering, so any additional casing hardware can be added to the same order.
- Inspect the seal or gasket around the inspection opening and replace it if it is perished or compressed.
Mechanical
| Part type | Casing assembly |
|---|---|
| Appliance family | Imax W45 / W60 |
Compliance
| Manufacturer part number (MPN) | 172629 |
|---|---|
| Barcode / EAN | 5022141726293 |
| Commodity code | 8403 90 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1178959 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — | |
| IDEAL COMMERCIAL IMAX W45 | 41-397-97 | 41-397-97 | — | — |
| IDEAL COMMERCIAL IMAX W45P - PROPANE | 41-399-01 | 41-399-01 | — | — |
| IDEAL COMMERCIAL IMAX W60 | 41-397-98 | 41-397-98 | — | — |
| IDEAL COMMERCIAL IMAX W60P - PROPANE | 41-399-02 | 41-399-02 | — | — |
