Ideal Tray 172130
Ideal 172130 casing tray for Ideal Commercial Concord ES180/H CPT and ESi 180 CPT appliances; previous number 8358-1562.
At a glance
- Part type: casing assembly
- Appliance family: Ideal Commercial Concord
- Also known as TRAY-8358-1562, 1178515
£508.93
£424.11 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 172130 is a casing tray supplied for Ideal Commercial Concord appliances. It forms part of the outer casing assembly, sitting at the base of the unit where it carries and shields the components housed in that section. The tray is matched to the Concord ES180/H CPT and ESi 180 CPT chassis, so it lines up with the existing fixing points and panel edges on those appliances.
Signs this part needs replacing
- Visible corrosion or rust scaling across the tray surface
- Water staining or pooling that has left the metal pitted or softened
- Distortion or bending that stops the tray seating squarely against the appliance frame
- Cracks, splits or holes that leave the lower casing open
- Fixing points or edges corroded to the point where the tray no longer secures properly
Before you order
- Confirm the appliance model and serial number against the compatibility list before ordering, as Concord variants differ.
- Check the number on the existing tray: 8358-1562 and 1178515 both refer to this component.
- Inspect the surrounding casing panels and fixings at the same time, since a corroded tray often sits alongside corroded fasteners.
Mechanical
| Part type | Casing Assembly |
|---|---|
| Appliance family | Ideal Commercial Concord |
Compliance
| Manufacturer part number (MPN) | 172130 |
|---|---|
| Barcode / EAN | 5022141721304 |
| Commodity code | 8403 90 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | TRAY-8358-1562, 8358-1562, 1178515 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD ES180/H CPT P/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES180/H CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ESi 180 CPT U/A | — | — | — | |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — |
