Ideal Pilot Burner Head CLAFF100 Injector Kit 171439
Ideal pilot burner head supplied with the CLAFF100 injector kit, part 171439, for a wide range of Ideal British Gas, Scottish Gas and Classic appliances.
At a glance
- Part type: Pilot burner head
- Also known as 1178191
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£38.53
£32.11 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The pilot burner head is the component that carries the standing pilot flame on an Ideal gas appliance. Gas passes through the gas valve and reaches the burner head, where it is ignited; the resulting flame then lights the main burner and, in turn, heats the water in the primary heat exchanger.
This is an Ideal Domestic Boiler Spares part, part number 171439, supplied together with the CLAFF100 injector kit. It is a gas-carrying component and is used across a large number of Ideal British Gas, Scottish Gas and Classic models.
Signs this part needs replacing
- The pilot flame fails to light, or lights and then goes out shortly afterwards
- A weak, lazy or yellow pilot flame instead of a steady blue flame
- The pilot flame lifts away from the burner head or will not hold on the thermocouple
- Soot or discolouration building up around the burner head and injector
- Repeated lockouts or ignition faults traced back to a poor pilot flame
Before you order
- Check the appliance GC number and model against the compatibility list before ordering, as this burner head is used across many Ideal variants.
- Confirm the numbers on the existing part against 171439, 1178191 and 079590.
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Pilot burner head |
|---|
Compliance
| Manufacturer part number (MPN) | 171439 |
|---|---|
| GC number | 308-347 |
| Barcode / EAN | 5022141714399 |
| Commodity code | 8403 90 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 079590, 1178191 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL BRITISH/SCOTTISH GAS 100 RD1 | 41-387-52 | 41-387-52 | — | — |
| IDEAL BRITISH/SCOTTISH GAS RD 130 | 41-397-62 | 41-397-62 | — | — |
| IDEAL BRITISH/SCOTTISH GAS RD 130 (SILVER) | 41-397-81 | 41-397-81 | — | — |
| IDEAL BRITISH/SCOTTISH GAS RD1 3100 | 41-392-25 | 41-392-25 | — | — |
| IDEAL CLASSIC FF 2 100 | 41-349-71 | 41-349-71 | — | — |
| IDEAL CLASSIC FF3100 | 41-392-01 | 41-392-01 | — | — |
| IDEAL CLASSIC HE 12 | 41-415-59 | 41-415-59 | — | — |
| IDEAL CLASSIC HE 15 | 41-421-45 | 41-421-45 | — | — |
| IDEAL CLASSIC HE 18 | 41-421-46 | 41-421-46 | — | — |
| IDEAL CLASSIC HE 9 | 41-415-58 | 41-415-58 | — | — |
Showing 10 of 80 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL appliance manual — BRITISH/SCOTTISH GAS 100 RD1 (GC 41-387-52)
manualmanualIDEAL appliance manual — BRITISH/SCOTTISH GAS RD 130 (GC 41-397-62), BRITISH/SCOTTISH GAS RD 130 (SILVER) (GC 41-397-81)
manualmanualIDEAL appliance manual — BRITISH/SCOTTISH GAS RD1 3100 (GC 41-392-25)
manualmanualIDEAL appliance manual — CLASSIC FF 2 100 (GC 41-349-71)
manualmanualIDEAL appliance manual — CLASSIC FF3100 (GC 41-392-01)
manualmanualIDEAL appliance manual — CLASSIC HE 12 (GC 41-415-59), CLASSIC HE 15 (GC 41-421-45), CLASSIC HE 18 (GC 41-421-46), CLASSIC HE 9 (GC 41-415-58)
manualmanualIDEAL appliance manual — CLASSIC LX RS230 (GC 41-387-33), CLASSIC LX RS240 (GC 41-387-34), CLASSIC LX RS250 (GC 41-387-35), CLASSIC LX RS260 (GC 41-387-36), CLASSIC RS230 (GC 41-387-10), CLASSIC RS240 (GC 41-387-11), CLASSIC RS250 (GC 41-387-12), CLASSIC RS260 (GC 41-387-13)
manualmanualIDEAL appliance manual — CLASSIC RS 30 (GC 41-429-35), CLASSIC RS 40 (GC 41-429-36), CLASSIC RS 50 (GC 41-429-37), CLASSIC RS 60 (GC 41-429-38)
manualmanualIDEAL appliance manual — CLASSIC SE 30 FF (GC 41-395-36), CLASSIC SE 30 FF (SILVER) (GC 41-397-71)
manualmanualIDEAL appliance manual — ELAN 2 CF230 (GC 41-429-56), ELAN 2 CF240 (GC 41-429-57), ELAN 2 CF250 (GC 41-429-58), ELAN 2 CF260 (GC 41-429-59)
manualmanualIDEAL appliance manual — ELAN 2 NF230 (GC 41-429-60), ELAN 2 NF240 (GC 41-429-61)
manualmanualIDEAL appliance manual — ELAN 2 RS230 (GC 41-429-51), ELAN 2 RS240 (GC 41-429-52), ELAN 2 RS250 (GC 41-429-53), ELAN 2 RS260 (GC 41-429-54), ELAN 2 RS275 (GC 41-429-55)
manualmanualIDEAL appliance manual — HENRAD WH FF100 (GC 41-349-93)
manualmanualIDEAL appliance manual — OPTIA FF100 (GC 41-392-01)
manualmanualIDEAL appliance manual — OPTIA HE 12 (GC 41-421-71), OPTIA HE 15 (GC 41-421-72), OPTIA HE 18 (GC 41-421-96), OPTIA HE 9 (GC 41-421-70)
manualNo technical questions yet for this part.
