Ideal Red Lead 170249
Ideal red lead, part 170249, a sealing component for Ideal Commercial Concord ES140/H, ES160/H and ES180/H boilers.
At a glance
- Part type: Gaskets, o-rings, seals and washers
- Also known as 1177490
Showing prices
£269.47
£224.56 ex. VAT · VAT at 20%
Available to order · 3 working days
Available to order · 3 working days
Not certain it's the right part? The technical team verifies fitment before dispatch — no charge, and it stops a second trip.Call the technical teamSend a technical question
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal red lead, part number 170249, is a sealing component listed in the gaskets, o-rings, seals and washers group of Ideal commercial spares. It is used on the Ideal Commercial Concord ES range of boilers. The part carries the previous number 94305027 and is also listed under 1177490.
Signs this part needs replacing
- Weeping or visible moisture at the joint the seal serves
- Hardening, cracking or flattening of the seal material
- Discolouration or staining around the joint face
- System pressure that drops and does not hold after topping up
- Water tracking onto nearby components or insulation
Before you order
- Match part number 170249 against the number on the old component before ordering.
- Check for the previous number 94305027, which may be marked on older stock.
- Confirm the boiler model and serial number against the compatibility list below.
- Isolate and depressurise the appliance before removing the old seal.
Mechanical
| Part type | Gaskets, o-rings, seals and washers |
|---|---|
| Colour | Red |
Compliance
| Manufacturer part number (MPN) | 170249 |
|---|---|
| Barcode / EAN | 5022141702495 |
| Commodity code | 3214 10 00 00 |
| Alternative numbers | 94305027, 1177490 |
| Previous numbers | 94305027 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD ES140/H CPT P/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES140/H CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES160/H CPT P/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES160/H CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES180/H CPT P/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES180/H CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES200/H CPT P/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES200/H CPT U/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES220/H CPT P/A | — | — | — | |
| IDEAL COMMERCIAL CONCORD ES220/H CPT U/A | — | — | — |
Showing 10 of 105 compatible appliances.
Fitment listings are a guide, not a guarantee. Plant-room assemblies get modified on site more often than not. Send us the GC number off the data badge and a photo of the existing valve and we will confirm before anything is dispatched.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
manual
IDEAL COMMERCIAL appliance manual — CONCORD ES140/H CPT P/A, CONCORD ES140/H CPT U/A, CONCORD ES160/H CPT P/A, CONCORD ES160/H CPT U/A, CONCORD ES180/H CPT P/A, CONCORD ES180/H CPT U/A, CONCORD ES200/H CPT P/A, CONCORD ES200/H CPT U/A, CONCORD ES220/H CPT P/A, CONCORD ES220/H CPT U/A, CONCORD ES260/H CPT P/A, CONCORD ES260/H CPT U/A, CONCORD ES300/H CPT P/A, CONCORD ES300/H CPT U/A, CONCORD ES340/H CPT P/A, CONCORD ES340/H CPT U/A, CONCORD ES380/H CPT P/A, CONCORD ES380/H CPT U/A
manualmanualIDEAL COMMERCIAL appliance manual — CONCORD ESi 140 CPT U/A, CONCORD ESi 160 CPT U/A, CONCORD ESi 180 CPT U/A, CONCORD ESi 200 CPT U/A, CONCORD ESi 220 CPT U/A, CONCORD ESi 260 CPT U/A, CONCORD ESi 300 CPT U/A, CONCORD ESi 340 CPT U/A, CONCORD ESi 380 CPT U/A
manualmanualIDEAL COMMERCIAL appliance manual — VICEROY GT, VICEROY GT10 C/W EOGB GAS HI/LOW BURNER, VICEROY GT10 C/W EOGB OI HI/LOW BURNER, VICEROY GT10 NUWAY GAS, VICEROY GT10 NUWAY OIL, VICEROY GT10 RIELLO GAS, VICEROY GT10 RIELLO OIL, VICEROY GT10 SPECIAL, VICEROY GT11 C/W EOGB GAS HI/LOW BURNER, VICEROY GT11 NUWAY GAS, VICEROY GT11 NUWAY OIL, VICEROY GT11 RIELLO GAS, VICEROY GT11 RIELLO OIL, VICEROY GT11 SPECIAL, VICEROY GT12 C/W EOGB GAS HI/LOW BURNER, VICEROY GT12 NUWAY GAS, VICEROY GT12 NUWAY OIL, VICEROY GT12 RIELLO GAS, VICEROY GT12 RIELLO OIL, VICEROY GT12 SPECIAL, VICEROY GT13 C/W EOGB GAS HI/LOW BURNER, VICEROY GT13 NUWAY GAS, VICEROY GT13 NUWAY OIL, VICEROY GT13 RIELLO GAS, VICEROY GT13 RIELLO OIL, VICEROY GT13 SPECIAL, VICEROY GT14 NUWAY GAS, VICEROY GT14 NUWAY OIL, VICEROY GT14 RIELLO GAS, VICEROY GT14 RIELLO OIL, VICEROY GT14 SPECIAL, VICEROY GT8 C/W EOGB GAS HIGH/LOW BURNER, VICEROY GT8 NUWAY GAS, VICEROY GT8 NUWAY OIL, VICEROY GT8 RIELLO GAS, VICEROY GT8 RIELLO OIL, VICEROY GT8 SPECIAL, VICEROY GT9 C/W EOGB GAS HIGH/LOW BURNER, VICEROY GT9 NUWAY GAS, VICEROY GT9 NUWAY OIL, VICEROY GT9 RIELLO GAS, VICEROY GT9 RIELLO OIL, VICEROY GT9 SPECIAL
manualmanualIDEAL COMMERCIAL appliance manual — VISCOUNT GTE, VISCOUNT GTE14 NUWAY GAS, VISCOUNT GTE14 NUWAY OIL, VISCOUNT GTE14 RIELLO GAS, VISCOUNT GTE14 RIELLO OIL, VISCOUNT GTE14 SPECIAL, VISCOUNT GTE15 NUWAY GAS, VISCOUNT GTE15 RIELLO GAS, VISCOUNT GTE15 SPECIAL, VISCOUNT GTE16 NUWAY GAS, VISCOUNT GTE16 RIELLO GAS, VISCOUNT GTE16 SPECIAL, VISCOUNT GTE17 NUWAY GAS, VISCOUNT GTE17 RIELLO GAS, VISCOUNT GTE17 RIELLO OIL, VISCOUNT GTE17 SPECIAL, VISCOUNT GTE18 RIELLO GAS, VISCOUNT GTE18 SPECIAL, VISCOUNT GTE19 RIELLO GAS, VISCOUNT GTE19 SPECIAL, VISCOUNT GTE20 NUWAY GAS, VISCOUNT GTE20 SPECIAL, VISCOUNT GTE21 NUWAY GAS, VISCOUNT GTE23 SPECIAL, VISCOUNT GTE25 NUWAY GAS, VISCOUNT GTE25 SPECIAL
manualmanualIDEAL COMMERCIAL appliance manual — VISCOUNT GTS14 BOILER ONLY, VISCOUNT GTS15 BOILER ONLY, VISCOUNT GTS16 BOILER ONLY, VISCOUNT GTS17 BOILER ONLY, VISCOUNT GTS18 BOILER ONLY, VISCOUNT GTS19 BOILER ONLY, VISCOUNT GTS20 BOILER ONLY, VISCOUNT GTS25 BOILER ONLY
manualNo technical questions yet for this part.
