Ideal Upper Baffle 541 LG 170145
Ideal 170145 upper baffle (541 LG) for Ideal Commercial Harrier GT and GTE series boilers; alternative numbers 82190017 and 1177403.
At a glance
- Part type: Upper baffle
- Also known as 1177403
£104.72
£87.27 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 170145 is an upper baffle, designated 541 LG, for Ideal Commercial Harrier series boilers. It sits in the upper flueway of the heat exchanger, where it slows and redirects the passage of hot flue gases so they give up more heat to the surrounding waterways. Correct baffle fitment keeps combustion efficiency up and helps prevent localised overheating of the heat exchanger surfaces.
Signs this part needs replacing
- Flue gas readings drifting high, indicating heat is passing through the boiler rather than being absorbed
- Visible distortion, cracking, erosion or heavy soot and scale build-up on the baffle plate
- Boiler short-cycling or locking out on an overheat condition
- Rattling or movement of baffle plates within the upper flueway
- Uneven combustion readings or sooting across the heat exchanger passages
Before you order
- Confirm the boiler model and serial number against the compatibility list before ordering
- Check the markings on the baffle being removed; 82190017 and 1177403 both identify this part
- Inspect the gaskets, seals and fasteners on the flue and heat exchanger access covers and renew any that are damaged
Mechanical
| Part type | Upper Baffle |
|---|
Compliance
| Manufacturer part number (MPN) | 170145 |
|---|---|
| Barcode / EAN | 5022141701450 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1177403 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL HARRIER GT | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 EOGB GAS HI/LOW | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 EOGB GAS ON/OFF | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 NUWAY GAS HI/LOW | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 NUWAY GAS ON/OFF | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 NUWAY OIL HI/LOW | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 NUWAY OIL ON/OFF | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 RIELLO GAS HI/LOW | — | — | — | |
| IDEAL COMMERCIAL HARRIER GTE5 RIELLO GAS ON/OFF | — | — | — |
Showing 10 of 46 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL COMMERCIAL appliance manual — HARRIER GT
manualmanualIDEAL COMMERCIAL appliance manual — HARRIER GTE, HARRIER GTE5 EOGB GAS HI/LOW, HARRIER GTE5 EOGB GAS ON/OFF, HARRIER GTE5 NUWAY GAS HI/LOW, HARRIER GTE5 NUWAY GAS ON/OFF, HARRIER GTE5 NUWAY OIL HI/LOW, HARRIER GTE5 NUWAY OIL ON/OFF, HARRIER GTE5 RIELLO GAS HI/LOW, HARRIER GTE5 RIELLO GAS ON/OFF, HARRIER GTE5 RIELLO OIL HI/LOW, HARRIER GTE5 RIELLO OIL ON/OFF, HARRIER GTE5 SPECIAL, HARRIER GTE6 NUWAY GAS HI/LOW, HARRIER GTE6 NUWAY GAS ON/OFF, HARRIER GTE6 NUWAY OIL HI/LOW, HARRIER GTE6 NUWAY OIL ON/OFF, HARRIER GTE6 RIELLO GAS HI/LOW, HARRIER GTE6 RIELLO GAS ON/OFF, HARRIER GTE6 RIELLO OIL HI/LOW, HARRIER GTE6 RIELLO OIL ON/OFF, HARRIER GTE6 SPECIAL, HARRIER GTE7 EOGB GAS HI/LOW, HARRIER GTE7 EOGB GAS ON/OFF, HARRIER GTE7 NUWAY GAS HI/LOW, HARRIER GTE7 NUWAY GAS ON/OFF, HARRIER GTE7 NUWAY OIL HI/LOW, HARRIER GTE7 NUWAY OIL ON/OFF, HARRIER GTE7 RIELLO GAS ON/OFF, HARRIER GTE7 RIELLO OIL ON/OFF, HARRIER GTE7 SPECIAL, HARRIER GTE8 EOGB OIL ON/OFF, HARRIER GTE8 NUWAY GAS HI OW, HARRIER GTE8 NUWAY GAS ON/OFF, HARRIER GTE8 NUWAY OIL HI OW, HARRIER GTE8 RIELLO GAS HI/LOW, HARRIER GTE8 RIELLO OIL ON/OFF, HARRIER GTE8 SPECIAL, HARRIER GTE9 NUWAY GAS HI/LOW, HARRIER GTE9 NUWAY GAS ON/OFF, HARRIER GTE9 NUWAY OIL HI/LOW, HARRIER GTE9 RIELLO GAS HI/LOW, HARRIER GTE9 RIELLO GAS ON/OFF, HARRIER GTE9 RIELLO OIL HI/LOW, HARRIER GTE9 SPECIAL
