Ideal Connection Plug Assembly 12 Way Single 155059

The Ideal 155059 is a 12-way single connection plug assembly, supplied as a wiring connector for Ideal Commercial appliances. It forms the plug half of a multi-pin electrical connection, carrying the control and interlock circuits between harness sections inside the appliance. It is listed under caps, plugs and sockets in the Ideal spares range and is used across the Concord CXA commercial boiler family.

• Intermittent or total loss of power to the appliance controls with the harness otherwise intact
• Fault codes or lockouts that clear when the plug is disturbed or reseated
• Visible scorching, discolouration or melted plastic around the plug body or pins
• Corroded, bent or retracted pins that no longer make reliable contact in the socket
• Cracked or brittle plug housing that will not latch securely

• Confirm the appliance model and GC number against the compatibility list before ordering, as the same plug body is used in several configurations
• Check the existing plug for pin count and keying, since a 12-way single plug must match the socket it mates with
• Inspect the mating socket and harness for damage at the same time, as a failed plug often accompanies heat or moisture damage in the connector
• Have any electrical work inside the appliance carried out by a competent person, and follow the manufacturer's isolation and wiring instructions
