Ideal Burner Assembly CXA 120 154811
Ideal 154811 main burner assembly for Concord CXA 110H, CXA 120 and CXAP propane commercial boilers.
At a glance
- Part type: Burner assembly
- Also known as 1177129
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£96.48
£80.40 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 154811 is a main burner assembly used in the Concord CXA range of commercial gas boilers. It carries the gas/air mixture to the burner head, where combustion takes place inside the heat exchanger. As a serviceable combustion component it is replaced when the burner surface, ports or mounting face deteriorate.
Signs this part needs replacing
- Flame lifts off the burner head or burns with a yellow, lazy appearance instead of a steady blue flame
- Sooting or blackening around the burner and heat exchanger, with carbon deposits visible on the burner surface
- Uneven flame pattern across the burner, with some ports burning and others cold
- Combustion readings that drift outside the expected CO/CO2 range and cannot be corrected by adjustment
- Ignition is unreliable or the burner fails to light cleanly across its full length
Before you order
- Check the appliance GC number and model plate against the compatibility list, as the Concord CXA and CXAP variants use different gas configurations
- Confirm the number on the existing burner matches 154811 or the alternative number 1177129 before ordering
- Inspect the burner mounting gasket and seals at the same time, as these are disturbed when the burner is removed
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Burner assembly |
|---|
Compliance
| Manufacturer part number (MPN) | 154811 |
|---|---|
| GC number | 41-391-48 |
| Barcode / EAN | 5022141548116 |
| Commodity code | 8416 20 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1177129 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD CXA 110H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXA 120 | 41-387-86 | 41-387-86 | — | — |
| IDEAL COMMERCIAL CONCORD CXA 120H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXAP 110H - PROPANE | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXAP 120H - PROPANE | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXS 110/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXS 120/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXS 120NG | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXSD 110/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXSD 120/H | — | — | — |
Showing 10 of 12 compatible appliances.
