Ideal Furnace Door Insulation 4/5 Section 153452

The Ideal 153452 is a furnace door insulation panel used on Ideal Commercial Falcon appliances. It sits within the furnace door assembly and forms part of the casing, covers and panels group of spares, insulating the door from the heat generated inside the combustion chamber. Keeping this insulation intact protects the door and surrounding casing from excessive heat and helps the appliance run as designed.

• Cracking, crumbling or flaking of the insulation surface on the furnace door
• Heat discolouration or scorching on the door panel or adjacent casing
• The insulation panel has come loose or detached from the door
• Casing surfaces around the door running noticeably hotter than usual
• Insulation debris collecting inside the combustion area or around the door seal

• Confirm the appliance model and serial number against the compatibility list, as this panel is listed for 4/5 section Falcon units.
• Compare the number on the part being removed with 153452 and the alternative numbers 1177012 and 82275504.
• Inspect the door seal and any gaskets at the same time, since the door is opened during replacement.
• No GC number is listed for this part, so identify the appliance by model and serial number.
