Ideal Burner Assembly with Pilot Bracket 150153
Ideal 150153 burner bar with pilot bracket for Concord CX and CXA commercial boilers, GC number E58-101.
At a glance
- Part type: Burner assembly
- Also known as 1176789
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£78.08
£65.07 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 150153 is a burner assembly supplied as a burner bar with an integrated pilot bracket. It forms the combustion surface inside the appliance, carrying the flame across the burner head and holding the pilot assembly in its correct position relative to the main burner ports.
It is an Ideal-manufactured component intended for the Concord CX and CXA commercial boiler range, including propane variants.
Signs this part needs replacing
- The pilot lights but will not hold, or the main burner fails to establish after ignition
- Uneven flame pattern across the burner bar, with some ports not lighting
- Visible corrosion, cracking or distortion of the burner bar after prolonged heat cycling
- Sooting or discolouration around the burner head and pilot bracket
- Repeated lockouts traced to the burner rather than the gas valve or ignition components
Before you order
- Check the GC number on the appliance data badge against E58-101 before ordering
- Confirm the existing burner carries the number 150153 or the alternative number 1176789
- Inspect the burner gasket and seals at the same time, as these are disturbed during replacement
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
Mechanical
| Part type | Burner Assembly |
|---|
Compliance
| Manufacturer part number (MPN) | 150153 |
|---|---|
| GC number | E58-101 |
| Barcode / EAN | 5022141501531 |
| Commodity code | 8403 90 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1176789 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD CX 40 SERIES 3 | 41-387-60 | 41-387-60 | — | — |
| IDEAL COMMERCIAL CONCORD CX 40P SERIES 3 - PROPANE | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXA 40 | 41-387-78 | 41-387-78 | — | — |
| IDEAL COMMERCIAL CONCORD CXA 40H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXA 40P - PROPANE | 41-387-78 | 41-387-78 | — | — |
| IDEAL COMMERCIAL CONCORD CXAP 40H - PROPANE | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXC 48 SERIES 3 | 41-394-32 | 41-394-32 | — | — |
| IDEAL COMMERCIAL CONCORD CXD 40 SERIES 3 | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXS 40/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXS 40NG | — | — | — |
