Ideal Burner Assembly CXi 110-180 139824
Ideal 139824 main burner assembly (burner bar) for Ideal Commercial Concord CXDI and CXi boilers; alternative part number 1176764.
At a glance
- Part type: Burner assembly (burner bar)
- Also known as 1176764
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
£84.71
£70.59 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 139824 is a main burner assembly, supplied as a burner bar, for Ideal Commercial gas boilers. It sits in the combustion chamber and distributes the gas and air mixture across the burner surface so that combustion takes place evenly along its length. It is a serviceable combustion component, so it is replaced when the bar itself becomes distorted, corroded or blocked.
Signs this part needs replacing
- Sooting or blackening on or around the burner bar
- An uneven flame pattern, with sections of the burner not lighting or flames lifting off the surface
- A yellow or lazy flame where a crisp blue flame is expected
- Rising carbon monoxide readings or a combustion analysis that will not settle within tolerance
- Visible corrosion, cracking, distortion or blocked ports on the burner bar
Before you order
- This part is fitted to a gas appliance; installation must be carried out by a Gas Safe registered engineer.
- Check the appliance model and serial number against the compatibility list before ordering, as this burner assembly is listed for Concord CXDI and CXi variants across the 110 to 180 range.
- Cross-reference the alternative part number 1176764 if you are working from an older parts listing.
Mechanical
| Part type | Spares - Burner |
|---|
Compliance
| Manufacturer part number (MPN) | 139824 |
|---|---|
| Barcode / EAN | 5022141398247 |
| Commodity code | 8416 20 00 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | 1176764 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD CXDI 110 | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 110/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 120 | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 120/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 140 | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 140/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 160 | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 160/H | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 180 | — | — | — | |
| IDEAL COMMERCIAL CONCORD CXDI 180/H | — | — | — |
Showing 10 of 26 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
IDEAL COMMERCIAL appliance manual — CONCORD CXDI 110, CONCORD CXDI 120, CONCORD CXDI 140, CONCORD CXDI 160, CONCORD CXDI 180
manualmanualIDEAL COMMERCIAL appliance manual — CONCORD CXDI 110/H, CONCORD CXDI 120/H, CONCORD CXDI 140/H, CONCORD CXDI 160/H, CONCORD CXDI 180/H
manualmanualIDEAL COMMERCIAL appliance manual — CONCORD CXSI 110, CONCORD CXSI 120, CONCORD CXSI 140, CONCORD CXSI 160, CONCORD CXSI 180
manualmanualIDEAL COMMERCIAL appliance manual — CONCORD CXSI 110/H, CONCORD CXSI 120/H, CONCORD CXSI 140/H, CONCORD CXSI 160/H, CONCORD CXSI 180/H
manualmanualIDEAL COMMERCIAL appliance manual — CONCORD CXi 110 SERIES 2, CONCORD CXi 120 SERIES 2, CONCORD CXi 140 SERIES 2, CONCORD CXi 160 SERIES 2, CONCORD CXi 180 SERIES 2
manualNo technical questions yet for this part.
