Vaillant
Vaillant Manifold Fan Assembly 116696
Manifold fan assembly for Vaillant Ecomax PRO and EcoTEC PLUS VU gas boilers, part number 116696.
At a glance
- Also known as 1375586
£150.86
£125.72 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Vaillant 116696 manifold fan assembly is the combustion air fan and manifold unit used on Vaillant Ecomax PRO and EcoTEC PLUS VU gas boilers. It draws combustion air through the manifold and delivers it to the burner, so the boiler can maintain a stable, correctly proportioned air/gas mixture. The part is supplied as the fan manifold assembly only.
Signs this part needs replacing
- Boiler locks out or fails to fire, with fan-related fault codes showing on the display
- Fan runs noisily, with rumbling, scraping or bearing whine from the fan housing
- Fan does not spin or spins intermittently when the boiler calls for heat
- Flue gas readings or combustion analysis fall outside the expected range
- Visible damage, distortion or contamination around the manifold or fan housing
Before you order
- Confirm the appliance model and product number against the fitment list above
- Check the existing fan manifold assembly part number before removing it
- Inspect the fan and manifold seating for damage or debris on strip-down
- Confirm whether the fan is supplied separately from the manifold on your appliance variant
Compliance
| Barcode / EAN | 4024074432785 |
|---|---|
| Alternative numbers | 1375586 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| VAILLANT VAILLANT ECOMAX PRO 18E VU186-0 (41-044-30) | — | — | — | |
| VAILLANT VAILLANT ECOMAX PRO28E VU286-0 (41-044-31) | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 415 VU GB 156-2-0H | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 418 VU GB 186-2-0H | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 428 VU GB 286-2-0H | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 438 VU GB 386-2-0H | — | — | — | |
| VAILLANT VU 156 | 41-044-53 | 41-044-53 | — | — |
| VAILLANT VU 186 | 41-044-54 | 41-044-54 | — | — |
| VAILLANT VU 186-O | 41-044-30 | 41-044-30 | — | — |
| VAILLANT VU 286 | 41-044-55 | 41-044-55 | — | — |
Showing 10 of 26 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
VAILLANT appliance manual — VU 156 (GC 41-044-53), VU 186 (GC 41-044-54), VU 286 (GC 41-044-55), VU 286-O (GC 41-044-31), VU 386 (GC 41-044-57), ecoTEC PLUS 415 VU 156 (2006) (GC 41-044-53), ecoTEC PLUS 418 VU 186 (2006) (GC 41-044-54), ecoTEC PLUS 428 VU 286 (2006) (GC 41-044-55), ecoTEC PLUS 438 VU 386 (2006) (GC 41-044-57)
manualmanualVAILLANT appliance manual — VU 186-O (GC 41-044-30), ecoMAX PRO 18E VU 186-0 (2003-2006) (GC 41-044-30), ecoMAX PRO 28E VU 286-0 (2003-2006) (GC 41-044-31)
