Vokera
Vokera Main Burner Injector Manifold 10024742
Main burner injector manifold for Vokera Aquanova 17, EASI-FLO and RAIN 28 series gas boilers.
At a glance
- Part type: main burner injector manifold
- Also known as 1531645
£72.71
£60.59 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The main burner injector manifold is a Vokera gas boiler component that carries the burner injectors and distributes gas to the main burner. It is listed by the manufacturer under the burner category for the Aquanova 17, EASI-FLO and RAIN 28 appliance families. The manifold meters and directs the gas supply so the burner can light and burn evenly across its length.
Signs this part needs replacing
- Uneven flame across the burner, with some ports lighting and others not
- Yellow, lazy or lifting flame instead of a steady blue flame
- Sooting or blackening around the burner and heat exchanger area
- Repeated ignition lockouts or failure to establish a stable flame
- Reduced heat output that cannot be traced to gas pressure or the burner itself
Before you order
- Check the appliance data badge and confirm your model appears in the fits list above
- Confirm the part number on the manifold being removed matches 10024742
- Verify the injector sizes fitted to the existing manifold before ordering
- Isolate the gas supply and follow the manufacturer's instructions for burner removal and recommissioning
Compliance
| Alternative numbers | 1531645 |
|---|
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| VOKERA AQUANOVA 17 | — | — | — | |
| VOKERA EASI-FLO (BOILER CODE 20121684) | 52-094-06 | 52-094-06 | — | — |
| VOKERA RAIN 28 | 41-094-48 | 41-094-48 | — | — |
| VOKERA RAIN 28BI | 41-094-52 | 41-094-52 | — | — |
| VOKERA VOKERA AQUANOVA 17 | — | — | — | |
| VOKERA VOKERA EASI-FLO | — | — | — | |
| VOKERA VOKERA RAIN 28 | — | — | — | |
| VOKERA VOKERA RAIN 28B | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
No technical questions yet for this part.
