Johnson & Starley TTB Switch 1000-0503730
Thermodisc overheat switch for Johnson & Starley warm air units, part number 1000-0503730.
At a glance
- Part type: TTB switch (overheat device)
- Also known as 1690492
£33.47
£27.89 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The TTB switch (overheat device) is a thermodisc safety switch manufactured by Johnson & Starley for its warm air unit range. It monitors temperature at the appliance and interrupts the control circuit if an overheat condition develops. It is a serviceable safety component, not a general-purpose thermostat.
Signs this part needs replacing
- The appliance locks out or shuts down and will not restart until it has cooled
- Repeated overheat trips with no obvious cause elsewhere in the system
- The switch reads open circuit when tested, or fails to change state on temperature rise
- Intermittent operation or nuisance tripping during normal running
- Visible damage, scorching or loose terminals at the switch
Before you order
- Confirm the appliance model and variant, including any rear rising duct or propane version
- Check the existing switch marking and part number against 1000-0503730
- Verify the fault is at the overheat device and not a circulation, airflow or control fault
- Isolate the electrical supply before removing or testing the switch
Compliance
| GC number | 386-634 |
|---|---|
| Alternative numbers | 1690492 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| JOHNSON & STARLEY HISPEC J32 WARM AIR UNIT - REAR RISING DUCT | 42-416-06 | 42-416-06 | — | — |
| JOHNSON & STARLEY HISPEC J32 WARM AIR UNIT PROPANE | 42-416-07 | 42-416-07 | — | — |
| JOHNSON & STARLEY HISPEC J32 WARM AIR UNIT PROPANE - REAR RISING DUCT | 42-416-08 | 42-416-08 | — | — |
| JOHNSON & STARLEY HISPEC J32 WARM AIR UNIT | 42-451-02 | 42-451-02 | — | — |
| JOHNSON & STARLEY HISPEC J65 WARM AIR UNIT | 42-451-14 | 42-451-14 | — | — |
| JOHNSON & STARLEY HISPEC J90 WARM AIR UNIT | 42-451-15 | 42-451-15 | — | — |
| JOHNSON & STARLEY HISPEC M31 WARM AIR UNIT | 42-451-10 | 42-451-10 | — | — |
| JOHNSON & STARLEY J55-65 WARM AIR UNIT | 42-417-68 | 42-417-68 | — | — |
| JOHNSON & STARLEY J70-90 MK2 MAF WARM AIR UNIT | 42-417-71 | 42-417-71 | — | — |
| JOHNSON & STARLEY J70-90 MK2 WARM AIR UNIT | 42-417-70 | 42-417-70 | — | — |
Showing 10 of 16 compatible appliances.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
JOHNSON & STARLEY appliance manual — HISPEC J32 WARM AIR UNIT - REAR RISING DUCT (GC 42-416-06), HISPEC J32 WARM AIR UNIT (GC 42-451-02), J55-65 WARM AIR UNIT (GC 42-417-68)
manualmanualJOHNSON & STARLEY appliance manual — HISPEC J32 WARM AIR UNIT PROPANE (GC 42-416-07), HISPEC J32 WARM AIR UNIT PROPANE - REAR RISING DUCT (GC 42-416-08)
manualmanualJOHNSON & STARLEY appliance manual — HISPEC J65 WARM AIR UNIT (GC 42-451-14)
manualmanualJOHNSON & STARLEY appliance manual — HISPEC J90 WARM AIR UNIT (GC 42-451-15)
manualmanualJOHNSON & STARLEY appliance manual — HISPEC M31 WARM AIR UNIT (GC 42-451-10)
manualmanualJOHNSON & STARLEY appliance manual — J70-90 MK2 MAF WARM AIR UNIT (GC 42-417-71), J70-90 MK2 WARM AIR UNIT (GC 42-417-70)
manualNo technical questions yet for this part.
