Alpha
Alpha Piezo Spark Generator Grey 1.018162
Alpha 1.018162 grey piezo spark generator for Alpha gas boilers, producing the ignition spark at the burner. Fits 107 Alpha models including CD12S and CD18R.
At a glance
- Part type: Piezo spark generator
- Also known as SPARK-GENERATOR-CD24SC, 1250230
Showing prices
£47.41
£39.51 ex. VAT · VAT at 20%
In stock
Order within 10m for same-day dispatch
Not certain it's the right part? The technical team verifies fitment before dispatch — no charge, and it stops a second trip.Call the technical teamSend a technical question
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Alpha 1.018162 is a piezo spark generator supplied in a grey housing. It generates the high-voltage spark that lights the burner on Alpha gas boilers, working alongside the ignition electrode and lead. The unit is a direct replacement for the original generator fitted across the Alpha CD range.
Signs this part needs replacing
- No spark at the ignition electrode when the boiler runs its ignition sequence
- Boiler repeatedly goes to lockout after a failed light-up
- Audible click from the generator but no spark at the burner
- Weak, intermittent or irregular spark that lights the burner only occasionally
- Spark tracking or arcing from a cracked or damp generator body
Before you order
- Check the GC number on the appliance data badge against the compatibility list before ordering
- Confirm the existing generator carries the number 1.018162, or the alternative number 1250230
- Inspect the ignition lead and electrode at the same time, as a damaged lead can mimic a failed generator
Mechanical
| Part type | Ignitors & Spark Generators |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
| Colour | Grey |
Compliance
| Manufacturer part number (MPN) | 1.018162 |
|---|---|
| GC number | E94-414 |
| Commodity code | 8543 70 90 00 |
| GPC classification | Household Boilers/Furnaces/Tank Water Heaters Replacement Parts/Accessories |
| Alternative numbers | SPARK-GENERATOR-CD24SC, 1250230 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| ALPHA ALPHA CD12S | — | — | — | |
| ALPHA ALPHA CD13R | — | — | — | |
| ALPHA ALPHA CD18R | — | — | — | |
| ALPHA ALPHA CD18S | — | — | — | |
| ALPHA ALPHA CD20S | — | — | — | |
| ALPHA ALPHA CD24C | — | — | — | |
| ALPHA ALPHA CD24R | — | — | — | |
| ALPHA ALPHA CD24S | — | — | — | |
| ALPHA ALPHA CD28C EXTRA | — | — | — | |
| ALPHA ALPHA CD28C EXTRA LPG | — | — | — |
Showing 10 of 107 compatible appliances.
Fitment listings are a guide, not a guarantee. Plant-room assemblies get modified on site more often than not. Send us the GC number off the data badge and a photo of the existing valve and we will confirm before anything is dispatched.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
manual
ALPHA appliance manual — ALPHA ECO BOILER
manualmanualALPHA appliance manual — CD12S (GC 41-532-16), CD12S (LPG) (GC 41-532-17), CD20S (GC 41-532-18), CD20S (LPG) (GC 41-532-19), CD28S (GC 41-532-20), CD28S (LPG) (GC 41-532-21)
manualmanualALPHA appliance manual — CD13R (GC 41-532-05), CD13R (LPG) (GC 41-532-11), CD18R (GC 41-532-03), CD18R (LPG) (GC 41-532-09), CD24R (GC 41-532-04), CD24R (LPG) (GC 41-532-10)
manualmanualALPHA appliance manual — CD18S (GC 41-532-06), CD18S (LPG) (GC 41-532-13), CD30S (GC 41-532-08), CD30S (LPG) (GC 41-532-14)
manualmanualALPHA appliance manual — CD24C (GC 47-532-19), CD24C (LPG) (GC 47-532-29), CD24S (GC 41-532-02), CD24S (LPG) (GC 41-532-15), CD32C (GC 47-532-21), CD32C (LPG) (GC 47-532-30)
manualmanualALPHA appliance manual — CD25C (GC 47-532-31), CD25C (LPG) (GC 47-532-32), CD28C (GC 47-532-33), CD28C (LPG) (GC 47-532-34), CD28C EXTRA, CD28C EXTRA (LPG), CD35C (GC 47-532-35), CD35C (LPG) (GC 47-532-36)
manualmanualALPHA appliance manual — CD25X (GC 47-532-39), CD25X (LPG) (GC 47-532-40), CD28X (GC 47-532-37), CD28X (LPG) (GC 47-532-38)
manualmanualALPHA appliance manual — CD50 (GC 47-532-24), CD50 (LPG)
manualmanualALPHA appliance manual — INTEC 40GS2
manualmanualALPHA appliance manual — InTEC 12S (GC 41-532-22), InTEC 12S (LPG) (GC 41-532-25), InTEC 18S (GC 41-532-23), InTEC 18S (LPG) (GC 41-532-26), InTEC 28S (GC 41-532-24), InTEC 28S (LPG) (GC 41-532-27)
manualmanualALPHA appliance manual — InTEC 24X (GC 47-532-45), InTEC 24X (LPG) (GC 47-532-52), InTEC 26C (GC 47-532-47), InTEC 26C (LPG) (GC 47-532-54), InTEC 28X (GC 47-532-46), InTEC 28X (LPG) (GC 47-532-53), InTEC 30C (GC 47-532-48), InTEC 30C (LPG) (GC 47-532-55), InTEC 34C (GC 47-532-49), InTEC 34C (LPG) (GC 47-532-56)
manualmanualALPHA appliance manual — InTEC 30C ErP (GC 47-532-48), InTEC 30C ErP (LPG) (GC 47-532-55), InTEC 34C ErP (GC 47-532-49), InTEC 34C ErP (LPG) (GC 47-532-56)
manualmanualALPHA appliance manual — InTEC 30GS (GC 47-532-50), InTEC 30GS (LPG) (GC 47-532-57), InTEC 40GS (GC 47-532-51), InTEC 40GS (LPG) (GC 47-532-58)
manualmanualALPHA appliance manual — InTEC 30GS ErP (GC 47-532-50), InTEC 30GS ErP (LPG) (GC 47-532-57), InTEC 40GS ErP (GC 47-532-51), InTEC 40GS ErP (LPG) (GC 47-532-58)
manualNo technical questions yet for this part.
