Alpha
Alpha M8 X 0.5mm Nut Pressure Tube 1.013716
M8 x 0.5 mm nut for the pressure tube on Alpha CB24, CB24X and SY24 LPG gas boilers.
At a glance
- Also known as NUT-FOR-PRESSURE-TUBE-M8X05, NUT-M8X05---PRESSURE-TUBE, 1250072
£4.96
£4.13 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Alpha 1.013716 is an M8 x 0.5 mm nut used on the pressure tube of Alpha gas boilers. It secures the pressure tube connection at the point where the tube meets the relevant boiler component. It is a small consumable fastener, listed in the screws, nuts, bolts and clips category of Alpha gas boiler spares.
Signs this part needs replacing
- Dampness, staining or a weep at the pressure tube joint
- Corrosion or pitting on the nut body or threads
- Rounded or damaged flats, making the nut difficult to tighten or remove
- A loose pressure tube connection with a resulting loss of pressure
- Repeated difficulty achieving a sound seal at the tube connection
Before you order
- Confirm the thread size required is M8 x 0.5 mm
- Check the boiler model against the fitment list above
- Inspect the pressure tube and mating connection for damage before refitting
- Confirm whether the nut alone is required or the tube assembly is also affected
Compliance
| Alternative numbers | NUT-FOR-PRESSURE-TUBE-M8X05, NUT-M8X05---PRESSURE-TUBE, 1250072 |
|---|
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| ALPHA CB24 | 47-532-15 | 47-532-15 | — | — |
| ALPHA CB24 (LPG) | — | — | — | |
| ALPHA CB24X | 47-532-14 | 47-532-14 | — | — |
| ALPHA CB24X (LPG) | — | — | — | |
| ALPHA SY24 | 41-532-01 | 41-532-01 | — | — |
| ALPHA SY24 (LPG) | — | — | — |
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
No technical questions yet for this part.
Not sure which part?
Search by part number, product name or brand — our technical team confirms fitment before anything is dispatched.
