Ideal Printed Circuit Board 11 Board 060560
Ideal 060560 printed circuit board, board 11 (408700), for Concord Super Series 3, Super Plus and Module Super Plus DBI commercial appliances.
At a glance
- Part type: Printed circuit board (board 11)
- Also known as 408700, 1171063
£580.85
£484.04 ex. VAT · VAT at 20%
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Ideal 060560 is a printed circuit board — board 11 — used in Ideal commercial heating appliances. It carries the control electronics that handle ignition sequencing, temperature regulation and the safety interlocks that keep the appliance running within its designed parameters. Ideal supplies it as a spare for the Concord Super Series 3 and Super Plus families.
Signs this part needs replacing
- The appliance locks out or fails to fire on a call for heat
- No response from the control panel or display
- Repeated error codes or intermittent shutdowns during a run cycle
- Heating or hot water output cycles erratically with no mechanical cause found
- Visible scorching, corrosion or damaged tracks on the existing board
Before you order
- Match the GC number on the appliance data badge against the compatibility list.
- Compare the numbers printed on the existing board with 060560, 1171063 and 408700 before ordering.
- Isolate the electrical supply and take anti-static precautions when handling and fitting the board.
- Check whether any gasket or seal disturbed during access needs replacing at the same time.
Mechanical
| Part type | Casings, Covers & Panels |
|---|---|
| Length | 0.1mm |
| Width | 0.1mm |
| Depth | 0.1mm |
Compliance
| Manufacturer part number (MPN) | 060560 |
|---|---|
| GC number | 770-833 |
| Barcode / EAN | 5022140605605 |
| Alternative numbers | 408700, 1171063 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| IDEAL COMMERCIAL CONCORD SUPER SERIES 3 - HORIZONTAL | — | — | — | |
| IDEAL COMMERCIAL CONCORD SUPER SERIES 3 - VERTICAL | — | — | — | |
| IDEAL COMMERCIAL IDEAL COMMERCIAL PARTS | — | — | — | |
| IDEAL COMMERCIAL IDEAL SUPER PLUS | — | — | — | |
| IDEAL COMMERCIAL MODULE SUPER PLUS DBI | — | — | — | |
| IDEAL COMMERCIAL SUPER PLUS 200/2 | — | — | — | |
| IDEAL COMMERCIAL SUPER PLUS 200/2 DBI | 41-415-68 | 41-415-68 | — | — |
| IDEAL COMMERCIAL SUPER PLUS 200/S | 41-415-68 | 41-415-68 | — | — |
| IDEAL COMMERCIAL SUPER PLUS 300/3 | — | — | — | |
| IDEAL COMMERCIAL SUPER PLUS 300/3 ALT | — | — | — |
Showing 10 of 17 compatible appliances.
