Vaillant
Vaillant Insulation 16mm 0020093190
16mm insulation with nut and washer for the heat exchanger on Vaillant ecoTEC Plus and Pro boilers.
At a glance
- Also known as 1383387
Showing prices
£75.07
£62.56 ex. VAT · VAT at 20%
Available to order · 3 working days
Available to order · 3 working days
Not certain it's the right part? The technical team verifies fitment before dispatch — no charge, and it stops a second trip.Call the technical teamSend a technical question
Same-day dispatch
Ordered by 4pm Mon–Fri, 10:30am Sat.
30-day returns
Unused, in original packaging.
What it is
The Vaillant 0020093190 is a 16mm insulation component for the heat exchanger, supplied with a nut and washer. It forms part of the heat exchanger assembly on Vaillant ecoTEC Plus and ecoTEC Pro boilers, where it seals and insulates the connection area. It is a serviceable part intended for replacement when the existing insulation has degraded.
Signs this part needs replacing
- Insulation is cracked, crumbling or breaking apart
- Visible heat damage or discolouration around the heat exchanger connection
- Insulation material is missing or has fallen away
- Debris from degraded insulation found in the surrounding area
- Signs of moisture or leakage at the insulated joint
Before you order
- Confirm your boiler model and variant against the fitment list above
- Check that the existing insulation measures 16mm
- Confirm the nut and washer are required for your installation
- Verify the part number 0020093190 against the appliance's parts list
Compliance
| Barcode / EAN | 4024074585030 |
|---|---|
| Alternative numbers | 1383387 |
| Make | Model / assembly | Reference | Years | Fitment |
|---|---|---|---|---|
| VAILLANT VAILLANT ECOTEC PLUS 612 VU 126-3-5 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 612 VU 126-3-5 R1 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 612 VU 126-5-5 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 612 VU 126-5-5 R1 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 615 VU 156-3-5 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 615 VU 156-3-5 R1 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 615 VU 156-5-5 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 615 VU 156-5-5 R1 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 618 VU 186-3-5 | — | — | — | |
| VAILLANT VAILLANT ECOTEC PLUS 618 VU 186-3-5 R1 | — | — | — |
Showing 10 of 170 compatible appliances.
Fitment listings are a guide, not a guarantee. Plant-room assemblies get modified on site more often than not. Send us the GC number off the data badge and a photo of the existing valve and we will confirm before anything is dispatched.
Documents & drawings
Everything we hold for this part. Where a document exists but we don't hold it, the technical team will source it from the manufacturer — usually the same working day.
manual
VAILLANT appliance manual — VU 126/3-5 (GC 41-044-44), VU 126/3-5 R1 (GC 41-044-44), VU 156/3-5 (GC 41-044-45), VU 156/3-5 R1 (GC 41-044-45), VU 186/3-5 (GC 41-044-46), VU 186/3-5 R1 (GC 41-044-46), VU 246/3-5 (GC 41-044-47), VU 246/3-5 R1 (GC 41-044-47), VU 306/3-5 (GC 41-044-48), VU 306/3-5 R1 (GC 41-044-48), VU 376/3-5 R1 (GC 41-044-49), VUW 246/3-3 R1 (GC 47-044-36), VUW 246/3-3 R2 (GC 47-044-36), VUW 246/3-5 (GC 47-044-31), VUW 246/3-5 R1 (GC 47-044-31), VUW 246/3-5 R3 (GC 47-044-31), VUW 286/3-3 (GC 47-044-30), VUW 286/3-3 R1 (GC 47-044-30), VUW 286/3-3 R2 (GC 47-044-30), VUW 316/3-5 (GC 47-044-32), VUW 316/3-5 R1 (GC 47-044-32), VUW 316/3-5 R3 (GC 47-044-32), VUW 376/3-5 R1 (GC 47-044-33), ecoTEC PLUS 612 VU 126/3-5 (2005-2005) (GC 41-044-44), ecoTEC PLUS 612 VU 126/3-5 R1 (2005-2006) (GC 41-044-44), ecoTEC PLUS 615 VU 156/3-5 (2005-2005) (GC 41-044-45), ecoTEC PLUS 615 VU 156/3-5 R1 (2005-2006) (GC 41-044-45), ecoTEC PLUS 618 VU 186/3-5 (2005-2005) (GC 41-044-46), ecoTEC PLUS 618 VU 186/3-5 R1 (2005-2006) (GC 41-044-46), ecoTEC PLUS 624 VU 246/3-5 (2005-2006) (GC 41-044-47), ecoTEC PLUS 624 VU 246/3-5 R1 (2005-2006) (GC 41-044-47), ecoTEC PLUS 630 VU 306/3-5 (2005-2005) (GC 41-044-48), ecoTEC PLUS 630 VU 306/3-5 R1 (2005-2006) (GC 41-044-48), ecoTEC PLUS 637 VU 376/3-5 R1 - 2006-2006 (GC 41-044-49), ecoTEC PLUS 824 VUW 246/3-5 (2005-2005) (GC 47-044-31), ecoTEC PLUS 824 VUW 246/3-5 R1 (2005-2006) (GC 47-044-31), ecoTEC PLUS 824 VUW 246/3-5 R3 (2011-2012) (GC 47-044-31), ecoTEC PLUS 831 VUW 316/3-5 (2005-2005) (GC 47-044-32), ecoTEC PLUS 831 VUW 316/3-5 R1 (2005-2006) (GC 47-044-32), ecoTEC PLUS 831 VUW 316/3-5 R3 (2011-2012) (GC 47-044-32), ecoTEC PLUS 837 VUW 376/3-5 R1 (2005-2006) (GC 47-044-33), ecoTEC PRO 24 VUW 246/3-3 R1 (2005-2006) (GC 47-044-36), ecoTEC PRO 24 VUW 246/3-3 R2 (2008-2012) (GC 47-044-36), ecoTEC PRO 28 VUW 286/3-3 (2005-2006) (GC 47-044-30), ecoTEC PRO 28 VUW 286/3-3 R1 (2005-2006) (GC 47-044-30), ecoTEC PRO 28 VUW 286/3-3 R2 (GC 47-044-30)
manualmanualVAILLANT appliance manual — VU 126/5-5 (GC 41-044-60), VU 126/5-5 R1 (GC 41-044-60), VU 156/5-5 (GC 41-044-61), VU 156/5-5 R1 (GC 41-044-61), VU 186/5-5 (GC 41-044-62), VU 186/5-5 R1 (GC 41-044-62), VU 246/5-5 (GC 41-044-63), VU 246/5-5 R1 (GC 41-044-63), VU 306/5-5 (GC 41-044-63), VU 306/5-5 R1 (GC 41-044-64), VU 376/5-5 (GC 41-044-65), VU 376/5-5 R1 (GC 41-044-65), VUW 246/5-5 (GC 47-044-40), VUW 246/5-5 R1 (GC 47-044-40), VUW 316/5-5 (GC 47-044-41), VUW 316/5-5 R1 (GC 47-044-41), VUW 376/5-5 (GC 47-044-42), VUW 376/5-5 R1 (GC 47-044-42), ecoTEC PLUS 612 VU 126/5-5 (2012-2012) (GC 41-044-60), ecoTEC PLUS 612 VU 126/5-5 R1 (2012-2013) (GC 41-044-60), ecoTEC PLUS 615 VU 156/5-5 (2012-2012) (GC 41-044-61), ecoTEC PLUS 615 VU 156/5-5 R1 (2012-2013) (GC 41-044-61), ecoTEC PLUS 618 VU 186/5-5 (2012-2012) (GC 41-044-62), ecoTEC PLUS 618 VU 186/5-5 R1 (2012-2013) (GC 41-044-62), ecoTEC PLUS 624 VU 246/5-5 (2012-2012) (GC 41-044-63), ecoTEC PLUS 624 VU 246/5-5 R1 (2012-2013) (GC 41-044-63), ecoTEC PLUS 630 VU 306/5-5 (2012-2012) (GC 41-044-63), ecoTEC PLUS 630 VU 306/5-5 R1 (2012-2013) (GC 41-044-64), ecoTEC PLUS 637 VU 376/5-5 (2012-2012) (GC 41-044-65), ecoTEC PLUS 637 VU 376/5-5 R1 (2012-2013) (GC 41-044-65), ecoTEC PLUS 824 VUW 246/5-5 (2012-2012) (GC 47-044-40), ecoTEC PLUS 824 VUW 246/5-5 R1 (2012-2013) (GC 47-044-40), ecoTEC PLUS 831 VUW 316/5-5 (2012-2012) (GC 47-044-41), ecoTEC PLUS 831 VUW 316/5-5 R1 (2012-2013) (GC 47-044-41), ecoTEC PLUS 837 VUW 376/5-5 (2012-2012) (GC 47-044-42), ecoTEC PLUS 837 VUW 376/5-5 R1 (2012-2013) (GC 47-044-42)
manualmanualVAILLANT appliance manual — VU 656-7 (GC 41-044-59), ecoMAX 665 VU 656-7 (2006-2006) (GC 41-044-59)
manualmanualVAILLANT appliance manual — VU 656/4-5 (GC 41-044-59), ecoTEC VU 656/4-5 (2007-2015) (GC 41-044-59)
manualmanualVAILLANT appliance manual — VUI 376/3-5 (GC 47-044-39), ecoTEC 937 VUI 376/3-5 (2006-2012) (GC 47-044-39)
manualmanualVAILLANT appliance manual — VUW 246/5-3 (GC 47-044-44), VUW 246/5-3 R1 (GC 47-044-44), VUW 246/5-3 R2 (GC 47-044-44), VUW 286/5-3 (GC 47-044-45), VUW 286/5-3 R1 (GC 47-044-45), VUW 286/5-3 R2 (GC 47-044-45), ecoTEC PRO 24 VUW 246/5-3 (2012-2012) (GC 47-044-44), ecoTEC PRO 24 VUW 246/5-3 R1 (2012-2013) (GC 47-044-44), ecoTEC PRO 24 VUW 246/5-3 R2 (2013-2015) (GC 47-044-44), ecoTEC PRO 28 VUW 286/5-3 (2012-2012) (GC 47-044-45), ecoTEC PRO 28 VUW 286/5-3 R1 (2012-2013) (GC 47-044-45), ecoTEC PRO 28 VUW 286/5-3 R2 (2013-2015) (GC 47-044-45)
manualNo technical questions yet for this part.
Not sure which part?
Search by part number, product name or brand — our technical team confirms fitment before anything is dispatched.
